ADTRAN NETVANTA 3100 Series Quick Start

N V
ET ANTA
D B
WITH IAL
P/N 1700600L2, 1700610L2
G S
ETTING TARTED
Two configuration methods are available for your NetVanta unit:
• Web-based graphical user interface (GUI)
• ADTRAN Operating System (AOS) command line interface (CLI)
The GUI lets you configure the main unit settings, and provides online guidance, explanations for
each setting, and configuration wizards to help you get started. However, using the AOS CLI may
be necessary for more advanced configurations.
A GUI
CCESS THE
You may access the GUI from any web browser on your network by following these steps:
1. Connect the router to your PC, using an Ethernet cable connected to one of the four ports on
the back of the unit (Ethernet 1, 2, 3, or 4).
2. Set your PC to a fixed IP address in the 10.10.10.0 /24 subnet. For example configure your
PC with the following settings:
IP Address: 10.10.10.2
Subnet Mask: 255.255.255.0
Neither a default gateway nor DNS server needs to be configured to connect to the unit. If
you cannot change your PC's IP address, you will need to change the Unit's IP address
using the CLI as explained in the section below.
3. Open a web browser and enter the unit's IP address in your browser address line as follows:
http://10.10.10.1. The default IP address is 10.10.10.1, but if you had to change the unit's IP
address using the CLI, enter that address in the browser line.
4. You will then be prompted for the user name and password (the default settings are admin
and password).
5. The initial GUI screen appears. You can access initial setup information by selecting Setup
Wizard from the menu on the left.
6. ADTRAN recommends changing the default password. Browse to System > Passwords. In
the Login Configuration section, enter a new Username and Password and select Apply
Changes.
By default, the NetVanta 3130 comes with an ADSL and an asynchronous
transfer mode (ATM) port already configured and enabled. The service
provider should provide a PVC (VPI/VCI) number, which will be used to
configure the ATM PVC.
C
ONFIGURE THE
1. Select the Getting Started link under the System menu. This brings up a side bar menu.
2. Select Step 1 - Configure the Public Interface at the top of the side bar menu to open the
ATM PVC menu.
3. Enter the PVC number and select an Interface Mode. Usually this is PPP or PPPoE;
however, if IP routing is chosen, you will need to enter an IP address.
Quick Start Guide, 61700600L2-13E, March 2015
3100 S
ERIES
U
ACKUP NIT
ATM PVC (N
R
OUTER
V 3130 O
ET ANTA
)
NLY
1
