Open Input Circuit Response (configuration bits 7 and 8)

For 1–5 Vdc and 4–20 mA inputs only, use this bit field to define the state of the
channel data word when your module detects an open circuit for that channel:
If you select zero on open input circuit, your module sets the channel data
word to zero during an open circuit condition.
If you select max. on open input circuit, your module sets the channel data
word to its full-scale value during an open circuit.
If you select min. on open input circuit, your module sets the channel data
word to its low-scale value during an open circuit.
The full-scale and low-scale values (max. and min. count limits) are determined
by the channel's data format and selected input range. See Table 4-2.
IMPORTANT: If a circuit opens, your module provides input signal
NOTE
values until it detects and flags the open circuit.

Input Filter Frequency (configuration bits 9 and 10)

Use this bit field to select one of four filters for a channel. The filter selected
affects the channel update time and noise rejection characteristics:
A lower filter frequency increases the noise rejection and effective
resolution, but it also increases the channel update time.
Chapter 5: Programming Examples
Selected
Actual Signal Limits
Input
Min.
Range
0–20 mA
0 mA
4–20 mA
+4 mA
±10 V
-10.25 V
0–10 V
-0.50 V
0–5 V
-0.50 V
1–5 V
+0.50 V
0–20 mA
0.0 mA
4–20 mA
+3.5 mA
Count Limits
Max.
Min.
+20 mA
0
+20 mA
+3277
See note ➁.
+10.25 V
+10.25 V
+5.50 V
+5.50 V
+20.5 mA
+20.5 mA
User's Manual Pub. 0300266-04 Rev. A
4-5
Max.
+16384
+16384
