Chapter 1: Module Overview
User's Manual Pub. 0300128-04 Rev. A
Description
Overall Drift
Current Inputs
Voltage Inputs-INI4vi only
Table 1-3. Physical Specifications
Description
LED Indicators
Recommended Cable
Wire Size (maximum)
Terminal Block
Table 1-4. Environmental Specifications
Description
Operating Temperature
Storage Temperature
Relative Humidity
Certifications
Hazardous Environment
Classifications
Specification
Offset: ±539 nA/°C
Gain: ±50.5 ppm/°C
Offset: ±352 µV/°C
Gain: 34.8 ppm/°C
Specification
Four green channel status indicators, one for
each channel
One green module status indicator
Belden 8761 (shielded, twisted-pair) or
equivalent
One 12–24 AWG wire per terminal
Removable (supplied)
Specification
0 to 60 °C (32 to 140 °F)
-40 to 85 °C (-40 to 185 °F)
5 to 95% non-condensing
Certifications
UL/CUL and CE
Class I Division 2 Groups A, B, C, D
