Wallbox eNext Series Installation Manual
J
Closing
Close the Charge Point as per the following steps of verification and operation.
P O W E R I N P U T
Before proceeding, make sure voltage is present in the terminal blocks.
For Three-Phase models pay special attention to Neutral Cable.
C A R E F U L W I T H T H E W I R E S
Before closing the unit, keep in mind that all cables should remain inside.
C H E C K T H E P L U G S ( S O C K E T /C O N N E C T O R )
Plugs should be in good condition before starting the unit.
E L E C T R I C A L P R O T E C T I O N S
If the unit includes electrical protections, rearm all of them.
C L O S I N G
Place the sealing washers on the screws and then place them in the 5 points indicated on the
Charge Point next page, to close it. Do not tight the screws yet.
C H E C K T H E B E AC O N L I G H T S
All beacon lights should light properly. Here's the reference:
C H A R G E P O I N T S TAT E B E AC O N S C O LO U R
A v a i l a b l e G r e e n
C h a r g i n g B l u e
F a u l t R e d
O P E R AT I O N
Check that no abnormal noise appears while the unit is charging.
24
