Specifications

Weight:
Temperature Sensors:
Temperature Thresholds:
Multi-purpose User Analogs:
Analog Input Range:
Analog Thresholds:
Battery Cell Inputs:
Analog Input Range:
Analog Thresholds:
Note: Cell inputs require the correct battery harness installed that is appropriate for the cell voltage you
are monitoring. Damage could occur without the external harness and could void your warranty.
Contact DPS Telecom support team if you require assistance regarding the battery harness options.
Protocols:
Dimensions:
Mounting:
Power Input:
Current Draw:
Fuse:
Interfaces:
Visual Interface:
Operating Temperature:
Operating Humidity:
RoHS:
3lbs (1.4kg)
3 Integrated Analog Sensors (for external probe)
4 per sensor
3
-90 to +90 VDC (or 4-20mA)
4 per analog channel
24
2V cell: 0 - 3VDC
12V cell: 0 - 17VDC
48V cell: 0 - 58VDC
4 battery cell
SNMPv1, SNMPv2c, DCPx, TELNET, HTTP, Email
1.7" H x 8.1" W x 7.1" D
(4.4 cm x 20.6 cm x 18.2 cm)
19" or 23" rack or wall mount
-48VDC
50mA @ -48VDC
1/2 Amp GMT Fuse
1 RJ45 10BaseT Ethernet port
1 DB9 front-panel craft port
3 - 1/8 Stereo connector for external temperature probes
RS232 Serial Port
12 - 4-pin analog connectors for battery cell input
10 Front Panel LEDs
4 Back Panel LED
32°–140° F (0°–60° C)
0%–95% non-condensing
