14.3

System Alarms Display Map

Display Points Alarm Point
Default
25
configuration
26 Undefined
MAC Address
27
not set
IP Address not
28
set
LAN hardware
29
error
SNMP
30
processing error
SNMP
31
community error
LAN TX packet
32
drop
Notification 1
33
failed
Notification 2
34
failed
Notification 3
35
failed
Notification 4
11 36
failed
Notification 5
37
failed
Notification 6
38
failed
Notification 7
39
failed
Notification 8
40
failed
41 NTP failed
42 Timed Tick
Serial 1 RcvQ
43
full
Dynamic
44
memory full
45 Unit reset
Description
The internal NVRAM may be damaged. The
unit is using default configuration settings.
Reserved for future use.
The MAC Address is not set.
The IP is not set.
The unit does not have a solid LAN link to
the hub, switch, or router.
SNMP trap address is not defined and an
SNMP trap event occurred.
Community string does not match your
SNMP master's community string.
An error occurred transmitting Data over
LAN.
A notification 1 event, such as a page or
email, was unsuccessful.
A notification 2 event, such as a page or
email, was unsuccessful.
A notification 3 event, such as a page or
email, was unsuccessful.
A notification 4 event, such as a page or
email, was unsuccessful.
A notification 5 event, such as a page or
email, was unsuccessful.
A notification 6 event, such as a page or
email, was unsuccessful.
A notification 7 event, such as a page or
email, was unsuccessful.
A notification 8 event, such as a page or
email, was unsuccessful.
Communication with Network Time Server
has failed.
Toggles state at constant rate as configured
by the Timed Tick timer variable. Useful in
testing integrity of SNMP trap alarm
reporting.
Serial port 1 (or appropriate serial port
number) receiver filled with 8 K of data (4 K if
BAC active).
Not expected to occur.
Unit has rebooted.
Table 14.1.1.A. System Alarms Descriptions
Solution
Login to the BVM's web browser and
configure the unit. Power cycle to see is
the alarm clears.
- - - - -
Call DPS Tech Support: (559) 454-1600
See Section "Quick Start: How to Connect
to the BVM 48 via Craft Port." If not using
the BVM over LAN, set the IP address to
255.255.255.255
If connecting to a hub you might require a
LAN crossover cable.
Define the IP Address where you would
like to send SNMP trap events, or
configure the event not to trap.
Verify both community strings to make
sure they match.
Verify that you can ping both devices.
Use RPT filter debug to help diagnose
notification problems.
Use RPT filter debug to help diagnose
notification problems.
Use RPT filter debug to help diagnose
notification problems.
Use RPT filter debug to help diagnose
notification problems.
Use RPT filter debug to help diagnose
notification problems.
Use RPT filter debug to help diagnose
notification problems.
Use RPT filter debug to help diagnose
notification problems.
Use RPT filter debug to help diagnose
notification problems.
Try pinging the Network Time Server's IP
Address as it is configured. If the ping
test is successful, then check the port
setting and verify the port is not being
blocked on your network.
To turn the feature off, set the Timed Tick
timer to 0.
Check proxy connection. The serial port
data may not be getting collected as
expected.
Call DPS Tech Support (559) 454-1600
If unintentional, call DPS Tech Support:
(559) 454-1600.
