12.3.2 Schedule

The Edit > Schedule menu is where you will tell the BVM exactly which days and times you want to
receive alarm notifications. You set 2 different schedules for each discrete base alarm.
Days of the week
Any Time
Notification Time
12.4

Multi-Purpose User Analogs

Each of the BVM's user-defined analog channels may be individually configured to monitor changing
analog values in your environment. The analog inputs natively measures voltage on a range of -90
to +90 VDC. By removing the lid of the unit, you can move a jumper to set the point to monitor 4 -
20mA.
Internal and external temperature sensors monitor the ambient temperature. Both sensors measure a
range of 32° F to 140° F (0° C to 60° C) within an accuracy of ± 1°. The external temperature sensor
provides external temperature readings by plugging the optional probe into the temperature port on the
BVM's back panel.
Fig. 11.10 - The Schedule creation screen
Notification Scheduling
From either Schedule 1 or 2, check which days you want to receive
notifications.
Select to tell the BVM you want to receive alarm notifications at any time
for the day(s) you've selected.
Used to tell the BVM to only send alarm notifications during certain hours
on the day(s) you've selected.
