DPS Telecom BVM 48 User Manual page 47

Display 14
Display 15
Display 16
Display 17
Display 18
*Note: "Cell/Analog/Temp/Power 16 Bit Voltage Data*" must be multiplied by the appropriate VBIT from table 14.2 in order to create a
Description
Cell 23 Minor Under, Minor Over
Cell 23 Major Under, Major Over
Cell 23 average Minor Under, Minor Over
Cell 23 average Major Under, Major Over
Cell 23 Range
Cell 23 Polarity
Cell 23 16 Bit Voltage Data*
Cell 24 Minor Under, Minor Over
Cell 24 Major Under, Major Over
Cell 24 average Minor Under, Minor Over
Cell 24 average Major Under, Major Over
Cell 24 Range
Cell 24 Polarity
Cell 24 16 Bit Voltage Data*
Pow er A Minor Under, Minor Over
Pow er A Major Under, Major Over
Pow er A Range
Pow er A Polarity
Pow er A Value
Pow er B Minor Under, Minor Over
Pow er B Major Under, Major Over
Pow er B Range
Pow er B Polarity
Pow er B Value
Analog 1 Minor Under, Minor Over
Analog 1 Major Under, Major Over
Analog 1 Range
Analog 1 Polarity
Analog 1 Value
Temp 1 Minor Under, Minor Over
Temp 1 Major Under, Major Over
Temp 1 Range
Temp 1 Polarity
Temp 1 Value
Analog 2 Minor Under, Minor Over
Analog 2 Major Under, Major Over
Analog 2 Range
Analog 2 Polarity
Analog 2 Value
Analog 3 Minor Under, Minor Over
Analog 3 Major Under, Major Over
Analog 3 Range
Analog 3 Polarity
Analog 3 Value
Temp 2 Minor Under, Minor Over
Temp 2 Major Under, Major Over
Temp 2 Range
Temp 2 Polarity
Temp 2 Value
Temp 3 Minor Under, Minor Over
Temp 3 Major Under, Major Over
Temp 3 Range
Temp 3 Polarity
Temp 3 Value
Table 14.1 cont.
displayable value.
Port Address
99 1
99 1
99
1
99
1
99
1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99
1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99
1
99
1
99 1
99 1
99
1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
43
Point
1, 2
3, 4
5, 6
7, 8
9-11
13
17-32
33, 34
35, 36
37, 38
39, 40
41-43
45
49-64
1, 2
3, 4
9-11
13
17-32
33, 34
35, 36
41-43
45
49-64
1, 2
3, 4
9-11
13
17-32
1 ,2
3, 4
41-43
45
49-64
1, 2
3, 4
9-11
13
17-32
1, 2
3, 4
41-43
45
49-64
1, 2
3, 4
9-11
13
17-32
1 ,2
3, 4
41-43
45
49-64
