Description
Access lock
Select L1L2L3 phase rotation
Select L1L3L2 phase rotation
TB configuration: Normal close
TB configuration: Normal open
5.1.5

Plant controller commands

Commands for plant
Description
Island
AMF
Peak shaving
Fixed power
Mains power export
Load take over
Semi-Auto mode
Test mode
Auto mode
Block mode
Lamp test
Ack. all alarms
Set to local start
Set to remote start
Set clock to 4 am
Switch log to print
Print log
Print status
Set parameter [1-4]
Select test type to simple
Select test type to load
Select test type to full
Activate capacity overrule
Deactivate capacity overrule
Select application [1-4]
Run my ID constant
Run my ID activate
Run one mains
Run all mains
Update mode local
Application note 4189341276B EN
Activates access lock.
Activates L1L2L3 as phase rotation direction.
Activates L1L3L2 as phase rotation direction.
Change the tie breaker in the application configuration to Normally closed.
Change the tie breaker in the application configuration to Normally open.
Island function mode.
AMF (Automatic Mains Failure) function mode.
Peak shaving function mode.
Fixed power function mode.
Mains power export function mode.
Load take over function mode.
Semi-auto running mode.
Test running mode.
Auto running mode.
Block running mode.
Activate lamp test (LEDs on display).
Acknowledge all alarms.
Select local start in a power management application.
Select remote start in a power management application.
Set the controller clock to 04h00.
Switch between event, alarm and battery log to print.
Print output.
Print output.
Choose the parameter set for nominal settings.
Test sequence selection.
Test sequence selection.
Test sequence selection.
Activates power capacity overrule.
Deactivates power capacity overrule.
Power management: Select the application from the controller.
Runs the connected mains (constant)
Runs the connected mains (one shot)
Only one mains breaker is closed at the time.
All mains breakers are closed at the time.
Running mode update for the local controller.
