Click on the Write
button to save the AOP settings.
In the top menu, click on the AOP 1
AOP LED colour priority
If an AOP LED has more than one output for selection of colour, the presented colour will follow this priority:
Priority
Colour
1
Red flashing
2
Red
3
Yellow flashing
4
Yellow
5
Green flashing
6
Green
More information
See the document Option X Additional display and operator panel 4189340702 UK for more information about AOPs.
3.4.4

Controlling a relay output with a single AOP button

In this example, the relay can be replaced by any other output, and the AOP button can be replaced by e.g. a binary input.
The button of the AOP-2 must be set to activate Virtual Event 1 (VE 1) (in this case).
In Logic 1, the VE 1 will activate the relay output (21). At the same time, the relay output (21) will remain ON, unless Virtual
Event 2 (VE 2) is activated (AND NOT VE 2).
In Logic 2, the VE 1 will activate VE 2 if the relay output (21) is ON (AND Relay output (21)).
Application note 4189341276B EN
button to open the virtual AOP display.
Page 13 of 50
