Description
MB synchronisation to DG deactivated
GB synchronisation to mains activated
GB synchronisation to mains deactivated
Mode shift activated
Mode shift deactivated
Autoswitch off selected
Autoswitch static selected
Autoswitch dynamic selected
Autoswitch all selected
MB parallel activated
No break transfer activated
MB close failure start activated
Three phase system
Split L1L3 phase system
Split L1L2 phase system
Single phase system
Genset group selected
Genset group plant selected
Inductive reference selected
Capacitive reference selected
Exclude from Run All activated
Power offset [1-3] activated
Cos phi offset [1-3] activated
Test application selected with output cmd
enabled
Test application selected with output cmd
disabled
BB Parameter set [1-2] used
BB Unom = Mains Unom used
Mains sync. inhibit activated
Mains sync. inhibited
Ethernet ready
L1L2L3 phase rotation active
L1L3L2 phase rotation active
4.4

Close before excitation (CBE)

These events are available for group tie breaker controllers only.
Application note 4189341276B EN
Mains breaker synchronisation deactivated.
Generator breaker synchronisation activated.
Generator breaker synchronisation deactivated.
Mode shift between a running mode and AMF (Automatic Mains Failure) activated.
Mode shift between a running mode and AMF (Automatic Mains Failure)
deactivated.
Auto-switch is not enabled.
Auto-switch enabled for static section.
Auto-switch enabled for dynamic section.
Auto-switch enabled for all sections.
Multiple mains are allowed to supply the same busbar.
No break transfer is active.
MB close failure start is active.
Three phase AC configuration.
Split L1L3-phase AC configuration.
Split L1L2-phase AC configuration.
Single phase AC configuration.
Genset group application selection.
Genset group plant application selection.
Inductive cos phi reference.
Capacitive cos phi reference.
Exclude one or more breakers when Run ALL is activated.
Power reference offset activated.
Cos phi reference offset activated.
Emulation with engine and breaker relay reaction.
Emulation without engine and breaker relay reactions.
Nominal busbar settings 1 or 2.
Busbar nominal voltage is equal to the generator nominal voltage.
The mains breaker sync. inhibit function is activated (this does not necessarily
inhibit the synchronisation of the mains breaker).
The mains breaker is in fact inhibited.
Ethernet is ready for read/write.
The phase rotation is L1L2L3.
The phase rotation is L1L3L2.
Notes
