Technical data

Performance specifications and guarantee only in connection with original spare and replacement
parts!
8.1

TIG 17, TIG 26, TIG 150, TIG 200

Welding torch polarity
(Direct voltage)
Guide type
Voltage measurement
max. Arc striking and volt-
age rating
Maximum welding current
100 % Duty cycle DC at
40° C (Direct voltage / Alter-
nating voltage)
Switching voltage Push-but-
ton
Switching current Push-but-
ton
Switching capacity Push-
button
Electrode types
Ambient temperature
Diameter
Protection classification for
the machine connections
(EN 60529)
Shielding gas
Gas flow
Hose package length
Operating weight*
Welding torch connection
Standards used
Safety marking
* A standard TIG welding torch TIG XX GD 5P 2T 4M is available as a reference. The weights of the
other TIG welding torches differ slightly.
099-011623-EW501
09.08.2021
TIG 17 TIG 26
140 A / 100 A 180 A / 130 A
Standard tungsten electrodes
0,5-2,4 mm 0,5-4,0 mm
0.02-0.09 inch 0.02-0.16 inch
IP3X IP2X
Shielding gas DIN EN 439
10-20 l/min
2.6-5.3 gal./min
1,0 kg 1,25 kg
2.2 lb. 2.76 lb.
Decentralised connection / Euro torch connector
See declaration of conformity (appliance documents)
Technical data
TIG 17, TIG 26, TIG 150, TIG 200
TIG 150
Normally negative
Manually operated
113 V (Peak value)
12 kV
150 A / 105 A
0,02 - 42 V
0,01 - 100 mA
max. 1 W
-10°C to +40°C
1,0-2,4 mm
0.04-0.09 inch
IP3X
4-12 l/min
1.1-3.2 gal./min
4, 8 m
157, 314 inch
1,05 kg
2.31 lb.
TIG 200
200 A / 140 A
1,6-3,2 mm
0.06-0.13 inch
IP3X
10-20 l/min
2.6-5.3 gal./min
1,25 kg
2.76 lb.
27
