EWM TIG 17 GD Operating Instructions Manual page 32

Replaceable parts
TIG 150
Item Order number
1.5 094-009663-00000
1.5 094-009664-00000
1.5 094-009665-00000
1.6 094-011999-00000
3 094-011758-00000
4 094-011760-00000
4.1 094-011979-00000
5.1 094-009658-00000
5.1 094-009659-00000
5.1 094-009660-00000
5.1 094-022685-00000
5.1 094-023020-00000
5.1 094-023021-00000
5.1 094-023022-00000
5.5 094-011755-00000
5.5 094-012406-00000
5.5 094-012667-00000
5.6 394-002038-00000
5.6 394-002357-00000
5.6 394-002358-00000
5.7 094-011984-00000
5.7 094-012669-00000
5.7 094-012671-00000
6.1 094-011752-00000
6.2 094-011753-00000
10.08 094-001004-00000
10.08 094-001005-00000
10.08 094-001006-00000
10.08 094-001007-00000
10.08 094-001008-00000
10.08 094-001009-00000
10.08 094-001010-00000
10.08 094-001011-00000
10.08 094-001380-00000
10.08 094-001381-00000
32
Type
GN DIF TIG 150-450/450SC, 12,5 x 50
mm
GN DIF TIG 150-450/450SC, 16 x 50
mm
GN DIF TIG 150-450/450SC, 19,5 x 50
mm
GN TIG Ø 24 mm, L 34 mm
ADAPT 150/260 XL
ISO TIG 150/260 XL
ISO TIG 150/260
DIF TIG 150-450/450SC, D=1,6 mm
DIF TIG 150-450/450SC, D=2,4 mm
DIF TIG 150-450/450SC, D=3,2 mm
DIF TIG 150-450/450SC Multilayer Ø 2.4
mm
DIF TIG 150-450/450SC Multilayer Ø 1.6
mm
DIF TIG 150-450/450SC Multilayer Ø 3.2
mm
DIF TIG 150-450/450SC Multilayer Ø 4.0
mm
COL 150/260 D=2.4MM
COL 150/260 D=1.6MM
COL 150/260 D=3.2MM
CDIF TIG 150/260 Multilayer 2.4 mm
CDIF TIG 150/260 Multilayer 1.6 mm
CDIF TIG 150/260 Multilayer 3.2 mm
COL DIF 150/260 D=2.4MM
COL DIF 150/260 D=1.6MM
COL DIF 150/260 D=3.2MM
TCS TIG 150/260
TCM TIG 150/260
WCe 20; 1.6 x 175 mm
WCe 20; 2.4 x 175 mm
WCe 20; 3.2 x 175 mm
WCe 20; 4.0 x 175 mm
WP; 1.6 x 175 mm
WP; 2.4 x 175 mm
WP; 3.2 x 175 mm
WP; 4.0 x 175 mm
WCe 20; 1.0 x 175 mm
WCe 20; 2.0 x 175 mm
Designation
Gas nozzle for gas diffuser,
JUMBO
Gas nozzle for gas diffuser,
JUMBO
Gas nozzle for gas diffuser,
JUMBO
Gas nozzle for gas diffuser,
JUMBO
Adapter ring, JUMBO
Insulator, JUMBO
Insulator
Gas diffuser, JUMBO
Gas diffuser, JUMBO
Gas diffuser, JUMBO
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Electrode holder
Electrode holder
Electrode holder
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser
Gas diffuser
Gas diffuser
Back cap, short
Back cap, medium
Tungsten electrode, grey
Tungsten electrode, grey
Tungsten electrode, grey
Tungsten electrode, grey
Tungsten electrode, green
Tungsten electrode, green
Tungsten electrode, green
Tungsten electrode, green
Tungsten electrode, grey
Tungsten electrode, grey
