4.2
Connection variants
Item Symbol
1
2
3
4
5
6
099-011623-EW501
09.08.2021
Machine description – quick overview
Description
0
Decentral connection
Decentral welding current
Decentral connection – rotary gas valve
Decentral welding current, rotary gas valve
Euro central connection
Welding current and shielding included.
Euro torch connector – combination
Shielding gas integrated, decentral welding current
Welding current connection
Decentral
Euro torch connector
Shielding gas integrated.
Figure 4-2
Connection variants
