Item
Order number
1.5
094-009665-00000
1.6
094-011999-00000
4
094-009657-00000
4.1
094-011759-00000
5.1
094-009658-00000
5.1
094-009659-00000
5.1
094-009660-00000
5.1
094-009661-00000
5.1
094-022685-00000
5.1
094-023020-00000
5.1
094-023021-00000
5.1
094-023022-00000
5.5
094-009634-00000
5.5
094-009636-00000
5.5
094-009637-00000
5.5
094-009638-00000
5.6
094-004969-00000
5.6
094-006255-00000
5.6
094-023018-00000
5.7
094-009640-00000
5.7
094-009642-00000
5.7
094-009643-00000
5.7
094-009644-00000
6.1
094-010723-00000
6.2
094-010601-00000
10.08
094-001004-00000
10.08
094-001005-00000
10.08
094-001006-00000
10.08
094-001007-00000
10.08
094-001008-00000
10.08
094-001009-00000
10.08
094-001010-00000
10.08
094-001011-00000
099-011623-EW501
09.08.2021
Type
GN DIF TIG 150-450/450SC, 19,5 x
50 mm
GN TIG Ø 24 mm, L 34 mm
INS TIG 200/450 XL
INS TIG 200/450/450SC
DIF TIG 150-450/450SC, D=1,6 mm
DIF TIG 150-450/450SC, D=2,4 mm
DIF TIG 150-450/450SC, D=3,2 mm
DIF TIG 150-450/450SC, D=4,0 mm
DIF TIG 150-450/450SC Multilayer Ø
2.4 mm
DIF TIG 150-450/450SC Multilayer Ø
1.6 mm
DIF TIG 150-450/450SC Multilayer Ø
3.2 mm
DIF TIG 150-450/450SC Multilayer Ø
4.0 mm
COL 200/450 D=1.6MM
COL 200/450 D=2.4MM
COL 200/450 D=3.2MM
COL 200/450 D=4.0MM
200/450/SC Multilayer Ø 2.4 mm
200/450/SC Multilayer Ø 3.2 mm
200/450/SC Multilayer Ø 1.6 mm
COL DIF TIG 200/450/450SC, D=1,6
mm
COL DIF TIG 200/450/450SC, D=2,4
mm
COL DIF TIG 200/450/450SC, D=3,2
mm
COL DIF TIG 200/450/450SC, D=4,0
mm
TCS TIG 200/450/450SC
TCL TIG 200/450
WCe 20; 1.6 x 175 mm
WCe 20; 2.4 x 175 mm
WCe 20; 3.2 x 175 mm
WCe 20; 4.0 x 175 mm
WP; 1.6 x 175 mm
WP; 2.4 x 175 mm
WP; 3.2 x 175 mm
WP; 4.0 x 175 mm
Replaceable parts
Designation
Gas nozzle for gas diffuser,
JUMBO
Gas nozzle for gas diffuser,
JUMBO
Insulator, JUMBO
Insulator
Gas diffuser, JUMBO
Gas diffuser, JUMBO
Gas diffuser, JUMBO
Gas diffuser, JUMBO
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Electrode holder
Electrode holder
Electrode holder
Electrode holder
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser, multi-layer
Gas diffuser
Gas diffuser
Gas diffuser
Gas diffuser
Back cap, short
Back cap, long
Tungsten electrode, grey
Tungsten electrode, grey
Tungsten electrode, grey
Tungsten electrode, grey
Tungsten electrode, green
Tungsten electrode, green
Tungsten electrode, green
Tungsten electrode, green
TIG 200
35
