Mounting
6.4.2 Non-metallic vessels
1 Non-metallic vessel
2 Metal sheet or metal flange
To measure, Levelflex with a rod probe needs a metallic surface at the process connection.
Therefore:
• Select an instrument version with metal flange (minimum size DN50/2").
• Or: mount a metal sheet with a diameter of at least 200 mm (8") to the probe at the process
connection. Its orientation must be perpendicular to the probe.
No additional measures are required for coax probes.
24
2
1
Levelflex FMP51, FMP52, FMP54
Endress+Hauser
A0012527
