Pull-Cord Alarm; Acoustic Location Signal; Alarm With Location Information - ASCOM d83 User Manual

Alarm Operation
7.3

Pull-Cord Alarm

If needed, remove the pull-cord cover from the handset using a flat screwdriver before attaching the cord.
The cord must be attached more than 5 seconds before pulling it off the handset. If not, the alarm is not
triggered.
Make sure that the clip of the pull-cord is safely attached to the clothes.
When the alarm has been enabled but the cord is not attached to the handset, the Pull-cord alarm symbol
flashes to indicate that the cord must be attached to the handset. Also, if set by an administrator, a sound
signal is heard if the user does not react to the flashing icon.
When the Pull-cord alarm is triggered by pulling out the cord, depending on set parameters, the following
occurs:
• A beep is heard.
• The white LED flashes twice.
• The Pull-cord alarm symbol flashes.
• The vibrator stirs.
• The handset receives a notification that the alarm has been received by the system. This is a system
dependent feature.
• An acoustic location signal (ALS) may be activated after the alarm has been sent, or a call may be
established to a predefined number. See
after Alarm, page 49.
• Information about the handset's location is sent along with an alarm, see
Information, page 48.
• A sound signal alerts the user to re-attach the cord.
7.4

Acoustic Location Signal

An alarm can be followed by an Acoustic Location Signal (ALS). The ALS is a ramped up signal from the
handset that sounds for a predefined period of time. The signal is silenced by pressing the Mute button on
the handset.
Depending on the PDM/Device Manager settings, it is possible to make the user enter a password when
turning the ALS off. The password is the same as the phone lock password.
ALS is configurable for Man-down & No-movement alarm, Push-button alarm and Pull-cord alarm. Refer to
the Configuration Manual, Ascom d83 DECT Handset, TD 93426EN.
The ALS is not triggered if automatic call after alarm is active. However, if a call, for example an
automatic call after alarm, is already established during ALS, ALS will be silenced during this call.
7.5

Alarm with Location Information

Information about the handset's location can be sent along with an alarm. The location can be added as
follows:
• Manually by the user, see
• An approximate location given by the closest Base Station, refer to the Configuration Manual, Ascom
d83 DECT Handset, TD 93426EN.
48
7.4 Acoustic Location Signal, page 48
7.5.1 Alarm with Data, page
7.5 Alarm with Location
49.
TD 93434EN / 01 December 2021 / Ver. B
USER MANUAL
Ascom d83 DECT Handset
or 7.6 Automatic Call
