USER MANUAL
Descriptions
Ascom d83 DECT Handset
Microphone
The handset has two microphones:
• The microphone on the front bottom side for speech in voice communication.
• The microphone on the back side for noise cancelling during a phone call.
Battery
The battery is a rechargeable Li-Ion battery, placed under a battery cover.
The battery is fully charged within four hours.
The battery can be charged separately with a battery pack charger.
2.2

Chargers

This section includes information about the compatible chargers and programmers for the handset.
DC3 Desktop Charger and DP1 Desktop Programmer
Figure 2. DC3 Desktop Charger and DP1 Desktop Programmer
The DC3 Desktop Charger will only charge the handset, while the DP1 Desktop Programmer will download
new software and synchronize parameters. The handset is fully operational while placed in the charger.
The DC3 Desktop Charger is delivered with a plug-in power supply and is connected into an ordinary wall
socket.
IMPORTANT: The handset can only be used with DP1 marked DP1–AAAD and DC3 marked DC3-AxxD on
the labels.
Only use the charger within the temperature range of +5°C – +40°C.
CR3 Charging Rack
The CR3 Charging Rack is used for charging several handsets, to synchronize parameters, and for software
download. The built-in power supply can charge up to six handsets. For the details, refer to CR3, CR5, CR7,
Installation and Operation Manual, TD 92480EN.
Battery Pack Charger
The Battery pack charger is used for charging up to six spare batteries.
TD 93434EN / 01 December 2021 / Ver. B 7
