Procedure Call

When configuring the functions Call services, In Call menu, Contacts, or a shortcut or service to the Phone
call function, the data added in these functions is static. When entering the data for the function to be used,
a variable or character U can be entered that allows the user to enter additional numerical characters
before calling the number or sending the data to a system.
The Call services and In call menu features require configuration in WinPDM/Device Manager.
Refer to the following example for more information.
Example of configuration:
A user wants to create a service with the Phone call function. The PBX requires that a prefix must be added
to a phone number. In this case, the user can pre-program the prefix and then enter the applicable phone
number when using the Phone call function.
1. Press Menu.
2. Select Services.
3. Select Add new.
4. In the Name field, enter Call no. and press the OK soft key.
5. Select the function Phone call.
6. In the Number field, enter the prefix to be used followed by the character U. In this case, the text string
is as follows *21*U. The character U represents an Enter number dialog where the user can enter the
phone number.
7. Press Save.
When using the function, an Enter number dialog appears, see
the user enters 123 (or selects a contact with this number by pressing
*21*123 is dialled.
No call is established before the user presses OK, that is, post-dial.
Figure 11. Enter number dialog
TD 93434EN / 01 December 2021 / Ver. B
Figure 11. Enter number dialog, page
) and presses OK, the number
