User Manual
9d24 Mkll Cordless Telephone
2.3

EX-approved battery

Note: The 9d24 MkII EX-Messenger and 9d24 MkII EX-Protector shall be used with special
EX-approved batteries (P/N 660121).
The EX-approved battery should be marked with the text: "Battery charging or
replacement is NOT permitted in hazardous area." The EX-approved battery can only be
opened with a special Battery Pack Opener. See
2.4

Chargers

2.4.1

Desktop Charger

The Desktop Charger is used for charging your handset, for example at your desk. The
tilted design facilitates the use of handsfree operation, e.g. in loudspeaking mode. The
charger is delivered with a plug-in power supply and is connected into a wall socket.
Desktop Charger shall only be connected to power adapters supplied by the
manufacture.
Available Power Adapter is:
P/N FW7650/05 Power Supply unit AC/5V DC/1A.
Note: When charging an EX-version the Desktop Charger must be marked with DC2.
2.4.2

Charging Rack

Figure 3. Wall mounted Charging Rack with power supply
The Charging Rack is used for charging your handset and/or spare batteries. When
charging spare batteries an adapter is needed. The wall mounted Charging Rack and its
power supply are a modular system which enables a number of installation
configurations. Each power supply can support several charging racks with four positions
2007-02-07/ Ver. D
Figure 4.
Figure 5.
11.1 EX Battery on page 51.
TD 92333GB
5
