- Page 1 NÜVE SANAYİ MALZEMELERİ İMALAT VE TİCARET A.Ş. BM 15-BM 30 STIRRED WATER BATHS INSTRUCTION MANUAL Z14.K 25 098 Rev. No: 03 Rev. Tarihi: 01/2016...
- Page 2 Information contained in this document is the property of Nüve. It may not be duplicated or distributed without its permission. NÜVE SANAYİ MALZEMELERİ İMALAT VE TİCARET A.Ş. Saracalar Mah. Saracalar Kümeevleri No: 4/2 Akyurt 06750 Ankara-TURKEY : (90.312) 399 28 30 (pbx) : (90.312) 399 21 97 Sales : sales@nuve.com.tr Technical Service: service@nuve.com.tr...
- Page 3 INFORMATION CONTAINED IN THIS DOCUMENT IS THE PROPERTY OF NÜVE. IT MAY NOT BE DUPLICATED OR DISTRIBUTED WITHOUT PERMISSION. PLEASE REGISTER ONLINE TO VALIDATE YOUR WARRANTY: To register your warranty online, please visit our webpage www.nuve.com.tr and fill in the “Warranty Registration Form”.
-
Page 4: Table Of Contents
CONTENT Page INTRODUCTION 1.1. USE AND FUNCTION TECHNICAL SPECIFICATIONS 2.1. TECHNICAL SPECIFICATIONS TABLE 2.2. OPTIONAL ACCESSORIES PRECAUTIONS AND LIMITATIONS ON USE SYMBOLS INSTALLATION 5.1. ENVIRONMENTAL CONDITIONS 5.2. HANDLING AND TRANSPORTATION 5.3. UNPACKING 5.4. MAINS SUPPLY 5.5. POSITIONING 5.6. GENERAL PRESENTATION 5.7. -
Page 5: Introduction
1. INTRODUCTION 1.1. USE AND FUNCTION BM 15 and BM 30 Water Baths are designed to be used in bacterial culturing, cell culture, coagulation tests, coliform determination, enzyme reactions and other general and special applications. The BM Series provide temperatures between 5°C above the ambient temperature and 99.9 °C and keeps the temperature stable within the given tolerances. -
Page 6: Technical Specifications
K 52 019 Stainless steel lid for BM 30 K 52 008 Lid with 4 holes for BM 15 (Hole dia 95 mm) K 52 005 Lid with 4 holes for BM 30 (Hole dia 95 mm) K 52 006... -
Page 7: Precautions And Limitations On Use
Lid with 8 holes for BM 30 (Hole dia 95 mm) S 09 032 Blood Bag Basket for BM 30 R 01 045 Shelf for 6 x 100 ml flasks for BM 15 R 01 046 Shelf for 4 x 250 ml flasks for BM 15 R 01 047... -
Page 8: Symbols
This symbol refers to important circumstances. Labels on the device: Earthed Wall Socket BM 15 Fuses(2 x 5A) BM 30 Fuses(2 x 9A) 5. INSTALLATION 5.1. ENVIRONMENTAL CONDITIONS The water bath is designed to operate safely under the following conditions: ... -
Page 9: Unpacking
5.3. UNPACKING Open the packing cardboard box. Remove the nylon packing wrapped around the device. The items provided with the device are listed below, please check them. • 1 ea. user’s manual and warranty certificate • 1 ea. power cable •... -
Page 10: General Presentation
5.6. GENERAL PRESENTATION STIRRED TANK CONTROL PANEL Figure 1 Figure 2 5.7. CONTROL PANEL Figure 3... -
Page 11: Prior To Operation
1- Heating Process Display: This display shows the tank temperature during the operation and the set temperature value during programming. The error codes are also shown on this display. 2- Time Display: This display shows the elapsed time during the operation and the set value during programming. -
Page 12: Operating Principles
MAX. LINE Figure 4 6. OPERATING PRINCIPLES 6.1. OPERATING THE UNIT Switch on BM series stirred water bath by using the power switch and ensure that the power switch led is on. Observe that command and display panel is activated. ... -
Page 13: Completion Of The Operation
See “t ın” on the temperature display. Set the time value by pushing the value increase/decrease keys on the time adjustment side (1 minute to 99.9 hours or Hold) Push the time set key again. See “dly” on the temperature display. Set the delay time, after which the program starts, by pushing the value increase/decrease keys on the time adjustment side (1 minute to 99.9 hours or Hold) Push the time set key again to save the settings. -
Page 14: Periodic Maintenance And Cleaning
7. PERIODIC MAINTENANCE AND CLEANING 7.1. PERIODIC MAINTENANCE Regularly check the water level in the tank and add more if necessary. 7.2. CLEANING Prior to cleaning please unplug the device and clean the device at the room temperature. ... -
Page 15: Electrical Circuit Diagram
10. ELECTRICAL CIRCUIT DIAGRAM...
