NÜVE SANAYİ MALZEMELERİ İMALAT VE TİCARET A.Ş.
OT 020
BENCH TOP STEAM STERILIZER
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OT 020 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NUVE OT 020

  • Page 1 NÜVE SANAYİ MALZEMELERİ İMALAT VE TİCARET A.Ş. OT 020 BENCH TOP STEAM STERILIZER USER’S MANUAL...
  • Page 2 Tel : (00 90 312) 399 28 30 ( 3 lines ) Fax : (00 90 312) 399 21 97 e-mail: sales@nuve.com.tr WARRANTY CERTIFICATE Nüve warrants that the equipment delivered is free from defects in material and workmanship. This warranty is provided for a period of two years. The warranty period starts from the delivery date.
  • Page 3: Table Of Contents

    CONTENTS Page SECTION 1 USE AND FUNCTION SECTION 2 TECHNICAL SPECIFICATIONS 2.1. Technical Specifications Table 2.2. General View SECTION 3 INSTALLATION PROCEDURE 3.1. Lifting and Transport 3.2. Contents of the Package 3.3. Mains Supply 3.4. Environmental Conditions 3.5. Positioning 3.6. Preparation to Sterilization 3.6.1 Filling in Distilled Water SECTION 4 OPERATION 4.1.
  • Page 4: Section 1 Use And Function

    OT 020 steam sterilizer is designed for the sterilization of unwrapped medical or dental instruments and materials used in laboratories with pressurized steam. The OT 020 steam sterilizer heats up to the temperatures between 110° C and 140° C and generates pressurised steam at the same temperatures according to the Pressurized Vessel Principle.
  • Page 5: General View

    2.2. General View Figure 1...
  • Page 6: Section 3 Installation Procedure

    1. Lid locking arms 2. Lid 3. Sterilization chamber lid 4. Shelf carrier 5. Water tank discharge tap 6. Manometer 7. Control panel 8. Distilled water filling line Figure 2 9. Safety valve 10. Power supply inlet with fuse 11. On/Off switch Fuses 12.
  • Page 7: Environmental Conditions

    A supply fitted with a circuit breaker should be used for protection against short-circuit in case of a isolation fault. 3.4. Environmental Conditions This steam sterilizer is designed to operate safely under the following conditions: • Indoor use only ° °...
  • Page 8: Operation

    4. OPERATION 4.1. Operating the Steam Sterilizer • Switch on the steam sterilizer. • See that the control panel activates. • Add water if MIN WATER LEVEL led is on. See section 3.6. • Open the lid by turning the flywheel arms on the counter-clockwise direction and remove the substances left in the chamber, if any exist.
  • Page 10 01. Temperature Display (° C): This is the display where the sterilization chamber temperature and the temperature set values are shown on. It displays the set value during programming and the sterilization chamber temperature any time during the run. 02. Time Display : This is the display where the sterilization time is counted down after the set temperature has been reached.
  • Page 11: Programming

    17. Overpressure Led : This led is on when the sterilization chamber pressure exceeds the safety limits. The heating is stopped immediately. Please contact to an authorized technical assistance of Nuve. 18. MAX WATER LEVEL led : This led is on when the water level in the tank is at the maximum level.
  • Page 12: Section 5 Cleaning And Periodical Maintenance

    5.1. Periodical Maintenance • Replace the sterilization chamber lid gasket once a year. Please contact to the authorized technical service of Nuve for this replacement. • Change the distilled water in the water tank once a week. (See the figure below) 5.2 .
  • Page 13 OFF: In case of a power cut during the run this error message is displayed, the program is cancelled, the instrument passes to the discharging process since the sterilization cycle is interrupted and the sterilization is invalid. Please contact to an authorized NUVE service in any case of error!
  • Page 14: Section 7 Electrical Circuit Diagram

    7. ELECTRICAL CIRCUIT DIAGRAM...
