Certification
6.2 EMC and Environmental Type Tests
•
6.2

EMC and Environmental Type Tests

The RUGGEDCOM RS416F has passed the following EMC and environmental tests.
IEC 61850-3 Type Tests
61000-4-2
61000-4-3
61000-4-4
61000-4-5
61000-4-6
61000-4-8
61000-4-29
61000-4-11
61000-4-12
40
IEC 61000-6-2
Electromagnetic Compatibility (EMC) – Part 6-2: Generic Standards – Immunity
for Industrial Environments
Test
IEC ESD
IEC Radiated RFI
IEC Burst (Fast Transient)
IEC Surge
IEC Induced (Conducted) RFI
IEC Magnetic Field
IEC Voltage Dips and Interrupts
IEC
IEC Damped Oscillatory
Description
Enclosure
Contact
Enclosure Air
Enclosure
ports
Signal ports
DC Power
ports
AC Power
ports
Earth
ground ports
Signal ports
DC Power
ports
AC Power
ports
Signal ports
DC Power
ports
AC Power
ports
Earth
ground ports
Enclosure
ports
DC Power
ports
AC Power
ports
Signal ports
DC Power
ports
Test Levels
± 8 kV
± 15 kV
20 V/m
± 4 kV @ 2.5 kHz
± 4 kV
± 4 kV
± 4 kV
2 kV
± 2 kV line-to-earth,
± 1 kV line-to-line
± 4 kV line-to-earth,
± 2 kV line-to-line
10 V
10 V
10 V
10 V
100 A/m
1000 A/m for 3 s
30% for 0.1 s,
100% for 0.05 s
30% for 1 period,
100% for 5 periods,
100% for 250 periods
2.5 kV common, 1 kV
differential mode @ 1 MHz
2.5 kV common, 1 kV
differential mode @ 1 MHz
Installation Manual, 04/2021, C79000-G8976-1354-04
Severity
Levels
4
4
a
Note
a
Note
4
4
4
3
3
4
3
3
3
3
a
Note
5
3
3
