Introduction
1.7.3 IEEE 1588 Support
3
Figure 1.3
The maximum number of devices (N) that can be connected to the source is
determined by checking if the source current (IS) required to drive the connected
devices is less than the maximum drive current the source can provide, and verifying
that the load voltage (VL) the connected devices see is greater than the minimum
required voltage.
1.7.3
IEEE 1588 Support
RUGGEDCOM RS416F supports various IEEE 1588 time synchronization capabilities
and provides synchronization in 2-step mode. This mode supports the following clock
types:
•
•
•
•
8
Device
IRIG-B Simplified Circuit Schematic
End-to-End Slave Clock
End-to-End Master Clock
Peer-to-Peer Slave Clock
Peer-to-Peer Master Clock
RUGGEDCOM RS416F
Installation Manual, 04/2021, C79000-G8976-1354-04
