User's Manual | ACOM 1200S | 1.8-54 MHz Linear Power Amplifier
Storage and Shipment
8.3.
8.3.1. Storage Environment
The amplifier may be kept packed in a dry, ventilated and unheated location (with no chemically active
substances such as acids or alkalis) within the following environment ranges:
Temperature range: -40 to +70 degrees Celsius (-40
•
Humidity: up to 75% @ +35 degrees Celsius (95
•
8.3.2. Shipping Size and Weight
WxDxH: Approx. 550x540x360 mm, 19.0 kg (21.7x21.3x14.2 inches, 41.9 lbs.);
•
8.3.3. Transportation
All types of transportation may be used, including storage in an aircraft baggage compartment at up to
12000 meters (40000 ft) above sea level.
8.3.4. Returning to the Service Provider
Should it be necessary to ship the amplifier, use the original packing as described below.
Switch off the amplifier, pull the line (mains) plug out of the outlet, disconnect all cables from the rear
panel of the amplifier (remove the ground connection the last), and then pack the amplifier in its original
carton.
August 2021
Figure 8-1 Packaging cardboard box
Figure 8-1 Packaging cardboard box
NOTICE
o
o
F to 158
F);
o
F).
S e c t i o n SPECIFICATIONS | Page 55 of 60
