Figure 7-1 Bottom View - Air Filters - Acom 1200S Installation, Operation And Maintenance Manual

• PS air filter
Please, see

Figure 7-1 Bottom view - Air Filters

- To remove the filter unscrew the 2 mounting screws (
Filters
- Using a small flat screwdriver or tweezers gently lift the filter tray away from the
amplifier body.
Carefully clean the filters and covers from dust, wash them with tap water and leave them to dry up before
you mount them back.
Finally, mount the air filters in place in reverse order described above and fasten the screws tightly.
2
4
The air filter may be too dusty - be careful how you clean it so that you DO NOT INHALE
(BREATHE IN) neither spill the dust over! Wrap it, for instance, in a wet cloth before
cleaning!
Page 46 of 60 | S e c t i o n MAINTENANCE
, Pos. (2).
, Pos. (4)), while holding the bottom;
Figure 7-1 Bottom view - Air Filters
Figure 7-1 Bottom view - Air Filters
CAUTION
User's Manual | ACOM 1200S | 1.8-54 MHz Linear Power Amplifier
1
Figure 7-1 Bottom view - Air
August 2021
3
5
