User's Manual | ACOM 1200S | 1.8-54 MHz Linear Power Amplifier
f) Main fuses
Please, see
Figure 2-2 Rear panel - Connections
If occasion should require replacement of the mains fuses, replace them as described in
Section
7.3 Fuse Replacement
g) The IEC 320 Power inlet
Please, see
Figure 2-2 Rear panel - Connections
Due to the different standards in different countries, the power supply cable and mains plug are supplied
and mounted by the dealer. He connects to the mains cord end a standard mains supply plug which meets
the Safety Class I unit standard in your country.
h) Preparation of wall outlet
Before connecting the amplifier to your mains supply using a licensed electrician, check
that the supply is correctly wired, and is adequate for the current drawn by the amplifier
(up to 10 A). Make certain that the grounding lead is connected properly and that it has
a cross section not less than the cross section of the phase conductor in the wall outlet
for the amplifier.
It is preferable that you use the wall outlet closest to the source. The installation leads should be at least
1.5 mm² (AWG 15 or SWG 17) at operating 200-240 VAC or 100-120 VAC (recommended values if there are
no stricter requirements by your local standard).
Check that the panel fuse has a free capacity for the additional load from the amplifier as specified in
Section Specifications
8.1.h) Mains Power Consumption at Full Output Power
different mains outlet, be sure that you check it, too.
Make sure the main rocker Power Switch (see
is in OFF position and insert amplifier's mains plug into the wall outlet prepared for it. The amplifier
remains switched off.
August 2021
, Pos. (f).
NOTICE
!
, Pos. (g).
WARNING
Figure 2-2 Rear panel - Connections
. If you connect the amplifier to a
, Pos. (3)), on the rear panel
S e c t i o n INSTALLATION | Page 19 of 60
