c) Protections:
Cover interlock for operator's safety;
•
Inrush power-on current limited to the nominal consumption;
•
Control grid, screen grid, and plate currents;
•
T/R sequencing;
•
Antenna relay contacts, including RF power induced in antenna from another nearby
•
transmitter;
Antenna matching quality;
•
Reflected power;
•
d) LED bar-graphs for forward peak power and reflected power;
e) Service visualization of grid 1 DC current, grid 2 DC voltage, and plate DC current;
f) Tube: a single Svetlana 4CX800A (GU74B) high-performance ceramic-metal tetrode with
plate dissipation of 800W, grid driven, forced air-cooling.

6.3. Storage and Shipment

Should it be necessary to ship the amplifier, use the original packing as described below.
Switch off the amplifier, pull the line (mains) plug out of the outlet, disconnect all cables
from the rear panel of the amplifier (remove the ground connection the last), and then
pack the amplifier in its original carton.
a) Acceptable storage environment: The amplifier may be kept packed in a dry, ventilated and
unheated location (with no chemically active substances such as acids or alkalis) within the
following environment ranges:
Temperature range: -40 to +70 degrees Celsius;
•
Humidity: up to 75% @ +35 degrees Celsius;
•
b) Shipping Size and Weight: WxDxH: 535x445x270mm, 19kg (21x17.5x10.6 inches, 41.9lbs.);
c) All types of transportation may be used, including storage in an aircraft baggage
compartment at up to 12000 meters above sea level.
