j) Measurement and/or constantly monitoring of 20 most important parameters of the amplifier via
RCU and/or PC.
k) Adjustable RCU Beep and Contrast.

7-3. Storage and Shipment

Should you need to transport the amplifier, use the original packing as described
below.
First pull the mains plug out of the mains outlet, afterwards disconnect all cables from the rear panel of
the amplifier (remove the ground connection last) and wait 30 minutes. Then remove the mains power
transformer, observing the requirements of S.2-3, but in reverse order. Pack the RCU in the box provided
for it, and put it in the amplifier in the place of the mains transformer. Screw in the transport board to
the transformer using the four shipping screws, pack the four shorter (mounting) bolts in the polyethylene
envelope. Finally mount the cover and pack the amplifier and transformer in their original cartons.
a) Storage environments: the amplifier can be kept packed in dry and ventilated unheated premises
without chemically active substances (acids, alkalies etc.) in the following climatic environment:
temperature range: -40 to +70 degs.Celsius;
humidity: up to 75% @ +35 degs.Celsius.
b) Shipping Size and Weight:
W390mm x D330mm x H350mm, 19kg - Transformer carton;
W630mm x D590mm x H310mm, 19kg - Amplifier carton.
c) Shipping environments: all types of transportation, including aircraft baggage section up to 12000
meters above sea level.
C A U T I O N
31
