7.3. Storage and Shipment

Should you need to transport the amplifier, use the original packing as described below.
First, switch off the amplifier. Pull the mains plug out of the outlet. Disconnect all cables from the rear
panel of the amplifier (remove the ground connection the last). Finally, pack the amplifier in its original
carton.
a) Storage environments: the amplifier can be kept packed in dry and ventilated unheated
premises without chemically active substances (acids, alkalis etc.) in the following climatic
environment:
Temperature range: -40 to +70°C;
•
Humidity: up to 75% @ +35°C;
•
b) Shipping Size and Weight: W560mm x D560mm x H300mm, 25kg (22 x 22 x 11.81 inches,
55.12lbs);
c) Shipping environments: all types of transportation, including aircraft baggage section up to
12 000 meters (40 000 ft.) above sea level.
