7. How to program the adjustable frequency drive

7.1. How to program
7.1.1. Parameter Set-up
177R0521-VLT_Aqua_Drive_Training_Handout_BODY.indd 42
Group Title
0- Operation/Display
1- Load / Motor
2- Brakes
3- Reference/Ramps
4- Limits/Warnings
5- Digital In/Out
6- Analog In/Out
8- Communication and Options
9- Profibus
10- DeviceNet Serial Communication
Bus
11- LonWorks
13- Smart Logic
14- Special Functions
15- Drive Information
16- Data Readouts
18- Info and Readouts
20- Drive Closed-loop
21- Extended Closed-loop
22- Application Functions
23- Time-based Functions
25- Basic Cascade Controller Func-
tions
26- Analog I/0 Option MCB 109
27- Extended Cascade Control
29- Water Application Functions
31- Bypass Option
7.1: Parameter Groups
Parameter descriptions and selections are displayed on the Graphic LCP or Numeric LCP in the
display area (see Section 5 for details.) Access the parameters by pressing the [Quick Menu] or
[Main Menu] key on the control panel. The quick menu is used primarily for commissioning the
unit at start-up by providing those parameters necessary to commence operations. The main menu
provides access to all the parameters for detailed application programming.
All digital input/output and analog input/output terminals are multifunctional. All terminals have
factory default functions suitable for the majority of water applications but if other special func-
tions are required, they must be programmed in parameter group 5 or 6.
MG.20.M2.22 - VLT
7. How to program the adjustable frequency
Function
Parameters related to the fundamental functions of the adjustable fre-
quency drive, the functions of the LCP buttons and the configuration of
the LCP display.
Parameter group for motor settings.
Parameter group for setting brake features in the adjustable frequency
drive.
Parameters for reference handling, defining limitations, and configuring
the reaction of the adjustable frequency drive to changes.
Parameter group for configuring limits and warnings.
Parameter group for configuring the digital inputs and outputs.
Parameter group for configuring the analog inputs and outputs.
Parameter group for configuring communications and options.
Parameter group for Profibus-specific parameters.
Parameter group for DeviceNet-specific parameters.
Parameter group for LonWorks parameters
Parameter group for Smart Logic Control
Parameter group for configuring special adjustable frequency drive func-
tions.
Parameter group containing adjustable frequency drive information such
as operating data, hardware configuration and software versions.
Parameter group for data readouts, such as current references, voltages,
control, alarm, warning and status words.
This parameter group contains the last 10 Preventive Maintenance logs.
This parameter group is used for configuring the closed-loop PID Con-
troller that controls the output frequency of the unit.
Parameters for configuring the three extended closed-loop PID control-
lers.
These parameters monitor water applications.
These parameters are for actions to be performed on a daily or weekly
basis, such as different references for working hours/non-working hours.
Parameters for configuring the Basic Cascade Controller for sequence
control of multiple pumps.
Parameters for configuring the Analog I/0 Option MCB 109.
Parameters for configuring the extended cascade control.
Parameters for setting water specific functions.
Parameters for configuring the bypass option
