Changing the drive parameters
Now that you have created a project drive, you can begin to manipulate the parameters.
The project drive should have identical parameters to the actual drive you will connect to
later if you entered the correct data when setting it up.
Saving & opening a project file (.SSP)
When you have finished editing the drive parameters you will need to save the project
file. Click "File" from the tool bar at the top of the screen and then chooses "Save As"
from the drop down menu. Name the file and click "Save" (it will be saved with a .SSP
file extension). You can now close the program. Locate the .SSP file that you saved and
open it. The project will reopen and the project drive will appear with the same parameter
settings that you had programmed previously.
177R0521-VLT_Aqua_Drive_Training_Handout_BODY.indd 39
Click the + next to the newly created project drive to expand the menu
Click the + next to "All Parameters" to access the main menu parameters
Click the + next to the main menu parameter group that you want to access
Click the sub parameter group that the desired parameter resides in
Double click the actual parameter of interest (under setup 1) and use the
drop down menus to make your selection
Click the OK button to accept the change
