Danfoss VLT AQUA Drive Manual page 36

Learn how to access and program the VLT AQUA Drives real time clock
Learn how to use the RTC to trigger different functions in the drive
Learn to control external devices with the AQUA drive RTC
Learn to use MCT-10 software wizards
Enhance your knowledge of the VLT AQUA Drives capabilities
Use the banana plugs to make the connections shown below. Identify the
terminals as you make your connections to help familiarize yourself with the I/O
terminals. Ask your instructor for help if you need assistance with this part.
