Altronix NetWay8V/NetWay16V Midspans provide power and pass data for PoE compliant cameras/edge devices. Cam-
eras/edge devices may be located up to 100m from the NetWay unit. A NetWayXT/NetWayXTX repeater module can be
utilized to extend the distance an additional 100m for a total range of up to 200m. A maximum range of 600m is possible
using multiple repeaters, based on camera/device port requirement. NetWay Midspans are capable of supporting non-PoE
compliant fixed and PTZ IP cameras utilizing NetWay1512 or NetWay3012 adapters.
NetWay8V:
• Eight (8) ports of cameras/edge devices over ethernet
(CAT5) cable up to a distance of 100m per port.
• 220VAC 50/60Hz, 1.8A (NetWay8V).
Agency Listings:
• CE Approved.
Power:
• Unit provides up to 30W max. full power per port.
Total power: NetWay8V - 150W, NetWay16V - 300W.
• IEEE 802.3af and IEEE 802.3at compliant (PoE Plus).
• Short circuit protection.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/edge devices.
• Illuminated master power disconnect circuit breaker
with manual reset (switch).
Features:
• Individual port status LEDs.
NetWay is not intended to be connected to outside plant leads.
1. Attach mounting brackets to NetWay unit for rack or wall mount installation (Figs. 7 or 8, pg. 10).
Affix rubber pads to NetWay for shelf installation (Fig. 9, pg. 10).
2. Secure the unit in a rack or place unit on a shelf as desired.
Note: The following factors should be taken into consideration when installing these rack mount units:
a. The unit is to be installed in a space where the maximum ambient temperature does not exceed 104ºF (40ºC).
b. Take care to insure there is sufficient air flow around the unit and that obstructions do not impede it.
c. When mounting units in rack, take care to avoid uneven loading which can cause a hazardous condition.
3. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 1d, pg. 3).
4. Plug the grounded AC line cord (included) into the IEC 320 connector of the NetWay unit (Fig. 1e, pg. 3).
Plug unit into a reliable earth grounded socket. When using multiple units the sum of the individual
name plate ratings should not exceed the supply circuit rating.
5. Connect structured cables from port marked [IN] on NetWay to the corresponding inputs of an ethernet switch or
video server (Fig. 1b, pg. 3, Fig. 5, pg. 5).
6. Connect structured cables from port marked [OUT] on NetWay to PoE compliant camera/edge
devices (Fig. 1a, pg. 3, Fig. 5, pg. 5).
7. Upon completion of wiring set illuminated master power disconnect circuit breaker to the RESET (ON)
position (Fig. 1d, pg. 3).
8. Port status LEDs on the NetWay will initialize when PoE devices are connected as follows:
- LED will illuminate when devices are IEEE 802.3af compliant.
- LED will blink once and illuminate when devices are IEEE802.3at compliant (PoE Plus).
- 2 -
Overview:
NetWay Specifications:
NetWay16V:
• Sixteen (16) ports of cameras/edge devices over ethernet
(CAT5) cable up to a distance of 100m per port.
• 220VAC 50/60Hz, 2.5A (NetWay16V).
Common Specifications:
Features (cont'd):
• IEC 320 - 3-wire grounded line cord (detachable).
• Unit can be rack or shelf mounted.
• 1U rack mount chassis for use in standard EIA 19" rack.
Accessories:
NetWay1512:
• 15W adapter for non-PoE compliant IP cameras.
NetWay3012:
• 25W adapter for non-PoE compliant IP
fixed or PTZ cameras.
NetWayXT:
• PoE repeater module extends range 100m.
NetWayXTX:
• PoE+ repeater module extends range 100m.

Installation Instructions:

NetWay8V/NetWay16V
