Altronix TROVE PLUS T1M1CK1Q Installation Manual

Access & Power Integration
Altronix/Mercury Wired Networked Kits
Models Include:
T1M1CK1Q
4 Door Kit with Fused Outputs
Accommodates one (1) Intelligent Dual Reader Controller and
one (1) Dual Reader Interface Module.
T1M1CK2Q
2 Door Kit with Fused Outputs
Accommodates one (1) Intelligent Controller and
one (1) Dual Reader Interface Module.
T1M1CK3Q
4 Door Kit with Fused Outputs
Accommodates up to two (2) Dual Reader Interface Modules.
Each fully assembled kit includes:
- Trove1 enclosure with TM1 Altronix/Mercury backplane
- One (1) eFlow4NB - Power Supply/Charger
- One (1) LINQ8PD - Networked Fused Power Distribution Module
- One (1) VR6 - Voltage Regulator
- One (1) Rocker Switch Bracket with One (1) Rocker Switch
- Wire harnesses and management
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. 020922
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T1M1CK1DQ
4 Door Kit with PTC Outputs
Accommodates one (1) Intelligent Dual Reader Controller and
one (1) Dual Reader Interface Module.
T1M1CK2DQ
2 Door Kit with PTC Outputs
Accommodates one (1) Intelligent Controller and
one (1) Dual Reader Interface Module.
T1M1CK3DQ
4 Door Kit with PTC Outputs
Accommodates up to two (2) Dual Reader Interface Modules.
Each fully assembled kit includes:
- Trove1 enclosure with TM1 Altronix/Mercury backplane
- One (1) eFlow4NB - Power Supply/Charger
- One (1) LINQ8PDCB - Networked PTC Power Distribution Module
- One (1) VR6 - Voltage Regulator
- One (1) Rocker Switch Bracket with One (1) Rocker Switch
- Wire harnesses and management
