Access & Power Integration
Altronix/CDVI Kits
Models Include:
T1CVK34D
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TC1 Altronix/CDVI backplane
- One (1) AL600ULXB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
T2CVK710D
10 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- One (1) AL1024ULXB2 - Power Supply/Charger
- One (1) ACM8CB - PTC Access Control Module
- One (1) ACM4CB - PTC Access Control Module
- One (1) PD8ULCB - PTC Power Distribution Module
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TCVLKD_090222
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2CVK3310
10 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- Two (2) AL600ULXB - Power Supply/Chargers
- Two (2) MOM5 - PTC Power Distribution Modules with
Fire Alarm Interface
T3CVK7720D
20 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with TCV3 Altronix/CDVI backplane
- Two (2) AL1024ULXB2 - Power Supply/Chargers
- Two (2) ACM8CB - PTC Access Control Modules
- One (1) ACM4CB - PTC Access Control Module
- One (1) PD8ULCB - PTC Power Distribution Module
- One (1) RSB2 - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL
More than just power.™
Advertisement
Related Manuals for Altronix TROVE T1CVK34D
Summary of Contents for Altronix TROVE T1CVK34D
- Page 1 10 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TC1 Altronix/CDVI backplane - Trove2 enclosure with TCV2 Altronix/CDVI backplane - One (1) AL600ULXB - Power Supply/Charger - Two (2) AL600ULXB - Power Supply/Chargers...
-
Page 2: Configuration Chart
Install the lower screws and make sure to tighten all screws. 3. Mount included UL Listed tamper switch(es) (Altronix Model TS112 or equivalent) in desired location, opposite hinge. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side (Fig. 1, pg. 2). Connect tamper switch wiring to the Access Control Panel input or the appropriate UL Listed reporting device. - Page 3 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 2 Fig. 2a TRIGGER INPUT IN GND IN GND IN GND IN GND Altronix - ACM4CB Altronix - AL600ULXB Spacer LED1 LED2 LED3 LED4 MAIN NC C NO COM...
- Page 4 Please make sure that they are mounted correctly, as shown in Fig. 3 below. 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 3 Fig. 3a RJ45 Jack Altronix AL1024ULXB2 Spacer CDVI - A22K/A22NB/ADH10 AC DELAY Backplane...
- Page 5 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 4 OFF - 24V ON - 12V Fig. 4a RJ45 Jack Altronix - AL600ULXB Spacer CDVI - A22K/A22NB/ADH10 AC DC BAT BAT FAIL NC C NO NC C NO AC FAIL Backplane...
- Page 6 OUTPUT 6 OUTPUT 7 OUTPUT 8 TRIGGER INPUT IN GND IN GND IN GND IN GND Altronix - ACM4CB LED1 LED2 LED3 LED4 MAIN NC C NO COM NC C NO COM NC C NO COM NC C NO COM...
- Page 7 T1CVK34D (Trove1) Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5” (38.1mm) 0.6”...
- Page 8 T2CVK710D and T2CVK3310 (Trove2) Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77”...
- Page 9 T3CVK7720D (Trove3) Enclosure Dimensions (H x W x D approximate): 36.12” x 30.125” x 7.06” (917.5mm x 768.1mm x 179.3mm) 2.00” (50.8mm) 7.12” (222.3mm) 9.5” (241.3mm) 9.5” (241.3mm) 1.25” (31.8mm) 1.55” (39.4mm) 1.78” (45.2mm) 1” Conduit 3/4” Conduit 1.5” Conduit 1.5”...
- Page 10 Notes: - 10 - Trove CDVI ULXB PTC Kits Installation Guide...
- Page 11 Notes: - 11 - Trove CDVI ULXB PTC Kits Installation Guide...
- Page 12 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IITrove CDVI ULXB PTC Kits I02V...
