Configuration Chart; Installation Instructions - Altronix TROVE T2SSK78 Installation Manual

Altronix T2SSK78 and T2SSK7514 Trove S2 kits are pre-assembled and consist of Trove enclosures/backplanes with factory installed Altronix
power supply/chargers and sub-assemblies. Both kits accommodate Lenel-S2 (S2 Security Platform) S2-INST Installation Kit for S2 Network
Node for up to eight (8) (T2SSK78(D)) or fourteen (14) (T2SSK7514(D)) doors in a single enclosure.
Power Power
Supply Supply
Board Board
Altronix Input Battery
Model Fuse Fuse
Number Rating Rating
T2SSK78
15A/
T2SSK78D
5A/
250V
T2SSK7514
15A/
T2SSK7514D
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes and authorities having jurisdiction.
Product is intended for indoor use only.
1. Remove backplane from enclosure. Do not discard hardware.
2. Mark and predrill holes in the wall to line up with the top two/three keyholes in the enclosure. Install two/three upper fasteners and
screws in the wall with the screw heads protruding. Place the enclosure's upper keyholes over the two/three upper screws;
level and secure. Mark the position of the lower three holes. Remove the enclosure. Drill the lower holes and install the three
fasteners. Place the enclosure's upper keyholes over the two/three upper screws. Install the three lower screws and make sure to
tighten all screws.
3. Mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) in desired
location, opposite hinge. Slide the tamper switch bracket onto the edge of the enclosure
approximately 2" from the right side (Fig. 1, pg. 2). Connect tamper switch wiring to the
Access Control Panel input or the appropriate UL Listed reporting device.
To activate alarm signal open the door of the enclosure.
4. Mount S2-INST Installation Kit to backplane, refer to pages 3, 4.
5. Refer to the ULXB Power Supply/Charger Installation Guide for AL1012ULXB,
AL1024ULXB2 and corresponding Sub-Assembly Installation Guides for ACM8,
PDS8, VR6 and PD8UL for further installation instructions.
Hardware:
Lock Nut
- 2 -

Configuration Chart:

Maximum Supply
Current for Main and
115VAC Aux. Outputs on
60Hz Power Supply board
Input and ACM8(CB) Access
Current Power Controllers'
(A) outputs
4.2 24VDC @ 9.7A
32V
24VDC @ 9.4A
6.9
32V
12VDC @ 10A

Installation Instructions:

Overview:
Nominal
DC Fail-
Output Safe/ Additional
Voltage Fail- Fused
Range Secure (PTC)
(VDC) Outputs Outputs
20.17-
8 8
26.4
20.17-
26.4
16 16
9.7-
13.2
ACM8 PDS8
ACM8 (CB) (CB)
(CB) Board Board
Board Output Input Output
Input Fuse Fuse
Fuse (PTC) (PTC)
Rating Rating Rating Rating
3.5A/ 10A/
250V 32V
10A/
250V
2.5A 9A
3.5A/
250V
10A/
–
250V
2.5A
Enclosure
Edge of
Enclosure
Tamper Switch
(included)
To Access Control Panel or
UL Listed Reporting Device
Trove2 S2 ULXB Kits Installation Guide
PDS8 PD8UL
(CB) (CB)
Board Board
Output
Fuse Fuse
(PTC) (PTC)
Rating
3A/
32V
–
2.5A
3.5A/
250V
–
2.5A
Fig. 1
