Altronix NetWay1E Installation Manual

The Altronix Netway1E/NetWay1EV is an enhanced 10/100/1000Base-T PoE++ midspan power injector. It is fully
compliant and backwards compatible with PoE (15W) and PoE+ (25W) PoE devices. The NetWay1E/NetWay1EV is
also capable of sourcing up to 85W with devices incorporating LTPoE++™ 70W, 52.7W & 38.7W, requiring up to 70W
of power at up to 100m (328').
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
Input:
• NetWay1E - 115VAC, 60Hz, 1.5 amp.
• NetWay1EV - 230VAC, 50/60Hz, 0.8 amp.
Data:
• One (1) PoE port provides power and passes data
over ethernet (CAT5) cable up to 100m (328 ft.).
• Data rate: 10/100/1000Base-T.
Output Power:
• IEEE 802.3af (15W) & IEEE 802.3at (25W)
compliant.
• Supports LTPoE++™ 70W, 52.7W & 38.7W PD
compliant devices up to 100m (328').
• Short circuit and overload protection.
Functions:
• PoE manual shutdown
• Auto detection and protection of legacy
non-PoE cameras/devices.
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes and
authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application.
NetWay1E/NetWay1EV is intended for indoor use only.
1. Place or mount NetWay1E/NetWay1EV in desired location (Fig. 1, pg. 2).
2. Plug the grounded AC line cord (included) into the IEC 320 connector of the NetWay1E/NetWay1EV unit. Plug unit
into a reliable earth grounded socket. When using multiple units the sum of the individual name plate ratings should
not exceed the supply circuit rating. Do not Connect To A Receptacle Controlled By A Switch.
3. Connect structured cable from UL Listed ethernet switch or video server to RJ45 jack marked [IN] on
NetWay1E/NetWay1EV (Fig. 1, pg. 2).
4. Connect structured cable from PoE device to RJ45 jack marked [OUT] on NetWay1E/NetWay1EV (Fig. 1, pg. 2).
5. PoE ON LED will illuminate indicating PoE device is turned on (Fig. 1, pg. 2).
6. The PoE output voltage may be shutdown by manually applying voltage in the rated range (12VAC to 24VAC or
5VDC to 24VDC) (PoE Shutdown Voltage Range in Specifications). Upon applying voltage the output will drop to
zero volts. Removal of voltage from the shutdown terminals or applying zero volts to the shutdown terminals will
allow the PoE output to operate normally to supply power to PoE compliant devices.
Note: Return to normal operation from shutdown can take about 4 seconds. When PoE power is remove, devices
may still present data signals on line pairs of the structured cable.
NetWay1E/NetWay1EV
®
Installation Guide
NetWay1E / NetWay1EV - Single Port PoE++ Injector
for Standard & Enhanced Power Network Infrastructure

Overview:

Features:

Installation Instructions:

Features:
• Port status LEDs.
• Manual PoE shutdown (Spring terminals).
• IEC 320 - 3-wire grounded line cord (detachable).
Electrical:
• Operating temperature:
85W: -20º C to 49º C ambient.
55W: -20º C to 55º C ambient.
• 32 BTU/Hr.
• System AC input VA requirement: 172.5VA.
Mechanical:
• Unit can be wall or shelf mounted.
• Enclosure Dimensions (H x W x D approx.):
1.625" (41.275mm) x 4" (101.6mm)
x 7.25" (184.15mm)
• Product weight (approx.): 2.2 lbs. (1.0 kg).
• Shipping weight (approx.): 3.2 lbs. (1.45 kg).
- 1 -
