Power over the Ethernet
NetWay G Series
PoE Midspan Solution for
Standard Network Infrastructure
Models Include:
NetWay81G
- Eight (8) Port PoE Midspan Injector
- 240W total power
NetWay81GL
- 8-Port Hi-PoE Midspan Injector
- 240W total power
Installation Guide
DOC#: NET1G Rev. 062922
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
NetWay81GP
- 8-Port Hi-PoE Midspan Injector
- 480W total power
NetWay161G
- Sixteen (16) Port PoE Midspan Injector
- 480W total power
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix NetWay G Series
Summary of Contents for Altronix NetWay G Series
- Page 1 Power over the Ethernet NetWay G Series PoE Midspan Solution for Standard Network Infrastructure Models Include: NetWay81G NetWay81GP - Eight (8) Port PoE Midspan Injector - 8-Port Hi-PoE Midspan Injector - 240W total power - 480W total power NetWay81GL NetWay161G...
-
Page 2: Table Of Contents
Table of Contents: Overview ..............pg. 3 Features . -
Page 3: Overview
Overview: Altronix NetWay81G, NetWay81GL, NetWay81GP and NetWay161G Midspans provide PoE/PoE+/Hi PoE (up to 60W) power per port, and pass data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup. Features:... -
Page 4: Terminal Description
Fig. 2 NetWay81G/81GL/NetWay81GP: NetWay81G/81GL/81GP - Front Panel NetWay81G/81GL/81GP - Rear Panel OUT 1-8 (1-16): Structured cable to PoE compliant cameras/edge devices. IN 1-8 (1-16): Structured cable to ethernet switch or video server. LEDs 1-8 (1-16): Port status LEDs. IEC 320 Connector: 115/230VAC (grounded line cord included). Built-in battery charger: Charges stand-by batteries for applications requiring back-up (optional rack mount battery enclosure available - RE2) NetWay161G... -
Page 5: Technical Specifications
Midspan or Endspan (10/100/1000) NetwayXTG Repeater Structured Port Status PoE/PoE+ LEDs Cable to Input www.altronix.com PoE/PoE+ PoE/PoE+ PoE/PoE+ Camera/Device or Input Output next NetWayXTG Installing a NetWayXTG Repeater Module: NetWayXTG will work with PoE/PoE+ devices. NetWayXTG is not intended to be connected to outside plant leads. -
Page 6: Installing A Netwayxt/Netwayxtx Repeater Module
Edge Device PoE/PoE+ or next IP Camera/Device or NetWayXT next NetWayXTX www.altronix.com Power –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– NetWayXT and NetWayXTX will work if the Midspan is set for 15W or 30W, but not 60W. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Installing a NetWayXT/NetWayXTX Repeater Module: NetWayXT will work only with PoE devices. NetWayXTX will work with PoE/PoE+ devices. -
Page 7: Netwayg Typical Applications
NetWay81G is shown (similar to NetWay81GL and NetWay81GP). NetWay161G is similar with twice as many ports Fig. 5 NetWayXT/NetWayXTX Brooklyn, NY, U.S.A. NetwayXT PoE/PoE+/Hi-PoE Repeater Extends Ethernet Camera 100m I.T.E. 43KC www.altronix.com Power Typical UL294 Card Application: Reader Camera Strike Transceiver Receiver Pace Long Range Ethernet Adapters Camera Extends Ethernet approx. -
Page 8: Mounting Options
Six (6) flat head screws for mounting brackets. Rubber Pad Four (4) rubber pads. Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
