Power over the Ethernet
NetWay V Series
PoE Solution for
Standard Network Infrastructure
Models Include:
NetWay8V
- Eight (8) Port PoE Midspan Injector
NetWay16V
- Sixteen (16) Port PoE Midspan Injector
Installation Guide
Rev. 071609
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix NetWay V Series
Summary of Contents for Altronix NetWay V Series
- Page 1 Power over the Ethernet NetWay V Series PoE Solution for Standard Network Infrastructure Models Include: NetWay8V - Eight (8) Port PoE Midspan Injector NetWay16V - Sixteen (16) Port PoE Midspan Injector Installation Guide More than just power. Rev. 071609 Installing Company: _______________ Service Rep. Name: __________________________________...
-
Page 2: Common Specifications
Overview: Altronix NetWay8V/NetWay16V Midspans provide power and pass data for PoE compliant cameras/edge devices. Cameras/edge devices may be located up to 100m from the NetWay unit. A NetWayXT/NetWayXTX repeater module can be utilized to extend the distance an additional 100m for a total range of up to 200m. A maximum range of 600m is possible using multiple repeaters, based on camera/device port requirement. - Page 3 Port Status and LED Flash Codes: Port Status Flash Codes Description All Ports Off Sequential LED Port Scan No devices connected Port Off LED OFF Port On LED ON Class 4 detection Port Blinks 2 times Enables power to PoE devices. Non-compliant Device Will prevent port from turning on.
- Page 4 Installing a NetWay1512 Adapter for 12VDC IP Cameras up to 13W: Fig. 2 - NetWay1512 Brooklyn, NY, U.S.A. Netway1512 I.T.E. Adapter 43KC www.altronix.com Structured Cable 12VDC -- + + Output --- from NetWay 12VDC Output Structured Cable from IP Camera/Device Power 1.
- Page 5 Fig. 4 - NetWayXT/NetWayXTX NetWayXT Brooklyn, NY, U.S.A. NetwayXT Repeater Structured Cable from NetWay8/16 Power Structured Cable to IP Camera/Edge Device I.T.E. 43KC or next NetWayXT www.altronix.com NetWayXTX Structured Power Cable from NetWay8/16 PoE/PoE+ Output LED PoE/PoE+ Port Status Structured Input...
-
Page 6: Technical Specifications
NetWay8V/NetWay16V Typical Application: Fig. 5 NetWayXT/NetWayXTX Extends Ethernet 100m (328 ft.) I.T.E. 43KC NetwayXT Repeater PoE Camera Card www.altronix.com Power Reader PoE Camera Strike HID Solo 12VDC NetWay1512 IP camera PoE + Camera Netway1512 Adapter I.T.E. 43KC www.altronix.com 12VDC + Output ---... - Page 7 NetWay8V/NetWay16V Rack Mount Chassis Mechanical Drawing and Dimensions: Fig. 6 0.75" (19.1mm) 19.125" (485.8mm) 17.625" (447.7mm) (ON) AC POWER 1.625" (41.3mm) The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient magnitude to constitute an electric shock.
-
Page 8: Rack Mount Installation
Four (4) rubber pads. Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IINetWay8V/NetWay16V...
