INVITE regest sends to outbound proxy adress. Outbound proxy
is used due NAT. When is not used dont fill up.
Port - SIP port is usually 5060 or 5061
SIP Transport - TCP or UDP, or automatic selection
Provisional code - determine if during ringing will be sends SIP code „180
Ringing" or „183 Session progress"
Enable symetric RTP - by mark is ON. It means that door entry will not sends
by itself audio to RTP called party, but wait for called party to send
RTP. After sends data to same adress:port from which message
arrived. It is trick used for bridging NAT.
In active mode - P2P is possible to operate device, which require for
their function registration at the SIP server. This option will use new SIP
phones, which generally do not support P2P mode, as well as applications for
iOS - Apple.
The principle of setting SIP phones and UDV guard, UDV Panel with IP
VarioBell:
1. Mode of phone is SIP server registration is IP address IP VarioBell
(registration or SIP server = IP address IP VarioBell)
2. Name and password is the line number (we choose a numbering plan
so that each number occurred in the network only once, then for each
device, fill in name and password to register with this number).
Example:
•
IP address of IP VarioBell is 192.68.1.250 and the name (page SIP
parameters) is 250
•
The IP address of SIP phone 1 is 192.168.1.200, fill in the registration
here - SIP server = 192.168.1.250 and name = password = 230
•
The IP address of SIP phone 2 is 192.168.1.201, fill in the registration
here - SIP server = 192.168.1.250 and name = password = 231
Call to SIP Phone 1 is 230, calls to SIP phone 2 is 231 and calls to IP
VarioBell is 250
