• Audio Only source selection Command Examples
This unit offers 4 direct audio only inputs, while some of these inputs
will likely be used for down mixed audio signals from surround sound
sources (for stereo only zones) we expect audio only sources to be
connected to deliver just audio to both TV zones and Audio Only
zones.
COMMAND
ZoneLineOut A AudioSrc=AnalogIn 1
ZoneLineOut A AudioSrc=OpticIn 1
ZoneLineOut A AudioSrc=CoaxIn 1
ExtLineOut 1 AudioSrc=AnalogIn 1
ExtLineOut 1 AudioSrc=OpticIn 1
ExtLineOut 1 AudioSrc=CoaxIn 1
Above are just a few example of the audio selections available.
Please refer to the full command listing for all possible commands.
Remember if you have configured any audio zones to play the OAR
audio from the TV within a zone you must be able to select this again
to return to "listening" to that TV.
• Individual Audio and Video Routing Command Examples
To offer the greatest level of flexibility the matrix can be used to send
individual commands for both video and audio, this allows the installer
to completely tailor the matrix to suit any possible configuration the
end user may require.
Route audio and video from HDMI input 1 to HDBaseT output A
independently:
COMMAND
HDBT_Out A VideoSrc=HDMI_In 1
HDBT_Out A AudioSrc=HDMI_In 1
16
DESCRIPTION
Route Analog input 1 to Zone
Audio output "A"
Route Optical input 1 to Zone
Audio output "A"
Route Coaxial input 1 to Zone
Audio output "A"
Route Analog input 1 to
Extended Line output "1"
Route Optical input 1 to
Extended Line output "1"
Route Coaxial input 1 to
Extended Line output "1"
DESCRIPTION
Video switch command
Audio switch command
