ExtremeRouting SLX 9640 Technical Specifications
Condition
Altitude (above
sea level)
Shock
Vibration
Airflow
Heat dissipation
(worst case)
Operating noise
MTBF (25°C, 60%
CL, Telec)
Worst case operational temperature is measured at sea level with at least 4 fan assemblies, with
maximum power consumption optics modules (5W QSFP28) fully loaded.

Power supply specifications (per PSU)

Power supply
model
XBR-
ACPWR-650-F
XBR-
ACPWR-650-R
XBR-
DCPWR-650-F
XBR-
DCPWR-650-R

Power consumption (typical configuration)

All 100-GbE ports are linked up, loading with 10 percent traffic rate. Six fan assemblies. Fans at nominal
speed.
@100 VAC Input (Input
power ±5%)
169 W
577 BTU/hr
178 W
607 BTU/hr
Operational
0 to 3,000 m (9,843 ft) safety
-60 to 4,000 m (13,123 ft) operational
20 G, 11 ms, half-sine wave
1 G sine, 0.4 grms random, 5-500 Hz
134 cfm (estimated with 2 power
supplies, 6 fan assemblies)
DC power supply 563 W
AC power supply 581 W
52.6 dBA (6 fan assemblies, 25°C,
typical loading)
306,419 hours with DC power supply
327,539 hours with AC power supply
Maximum Input voltage Input line
output
power
rating (DC)
650 W 100-240V~
650 W 100-240V~
650 W -48 - 60V
650 W -48 - 60V
@200 VAC Input
(Input power ±5%)
166 W
566 BTU/hr
176 W
601 BTU/hr
ExtremeRouting SLX 9640 Hardware Installation Guide
Power supply specifications (per PSU)
Non-operational
0 to 12,000 m (39,370 ft)
33 G, 11 ms, half-sine wave
2.4 G sine, 1.1 grms random, 5-500 Hz
N/A
N/A
N/A
N/A
Maximum
frequency input current
50-60Hz 12 A
50-60Hz 12 A
- 13.3 A
- 13.3 A
@-48VDC Minimum number
of power supplies
168 W 1 x 650 W AC
573 BTU/hr 1 x 650 W DC
179 W 1 x 650 W AC
611 BTU/hr 1 x 650 W DC
Input line Maximum
protection inrush
current
Fuses 35A
Fuses 35A
Fuses 40A
Fuses 40A
Notes
1 power supply
2 power supplies
