Providing power to the device

•
Optional: Access to an FTP server or USB device for backing up (uploading) or downloading the
device configuration or collecting diagnostic output data.
•
Optional: An Extreme USB drive for backing up (uploading) or downloading the device
configuration or collecting diagnostic output data.
Providing power to the device
After you complete the physical installation, you can power on the system.
1. Install alternating-current (AC) or direct-current (DC) power supplies in the switch. Refer to
Supplies
2. Connect AC or DC power cables to the power supply connectors on the rear panel.
3. Connect the power cables to the 100-240 VAC or 48-60 VDC power source. The power sources
should be on separate circuits to protect against power failure. Ensure that the power cords have a
minimum service loop of 6 inches available and are routed to avoid stress.
4. After the device has booted, verify that the power and status LEDs are green. The power supply
LEDs display amber until power-on self-test (POST) is complete, and then change to green. The
switch usually requires several minutes to boot and complete POST.
For more information about how to interpret LEDs and run diagnostics tests, refer to
page 75 section.

Establishing a serial connection

To establish a serial connection to the console port on the device, complete the following steps.
1. Verify that the device is powered on by verifying that all power LED indicators on the management,
interface, power supply, and fan modules display a steady green light.
2. Connect the RJ-45 serial cable provided with the device to the management Ethernet port of the
device.
Figure 30: Port-side view of the SLX 9640 Switch Router
56 ExtremeRouting SLX 9640 Hardware Installation Guide
on page 78 .
Note
The equipment should be installed near a power source and in an easily accessible
location.
Note
Power is supplied to the device as soon as the first power supply is connected.
Note
To turn the system off, simply unplug the power cables.
Initial Setup and Verification
Power
LED indicators on
