Power consumption (maximum configuration)

Power consumption (maximum configuration)
All 100-GbE ports are linked up, loading with 100 percent traffic rate. Two power supplies and six fan
assemblies. Fans at high speed.
@100 VAC Input (Input
power ±5%)
570 W
1,945 BTU/hr
581.2 W
1,983 BTU/hr

Data port specifications (Ethernet)

System component
QSFP28 ports
SFP+ ports
Ethernet management
port

Serial port specifications (pinout RJ-45)

Pin
1
2
3
4
5
6
7
8

Serial port specifications (pinout - mini-USB)

Pin
1
2
3
96 ExtremeRouting SLX 9640 Hardware Installation Guide
ExtremeRouting SLX 9640 Technical Specifications
@200 VAC Input @-48VDC
(Input power ±5%)
544.1 W 552 W
1,857 BTU/hr 1,884 BTU/hr
562.4 W 563 W
1,919 BTU/hr 1,921 BTU/hr
Description
100 GbE QSFP28 ports can support 40GE/4x10GE/100GE/
4x25GE/2x50GE interfaces.
The SFP+ ports can support 10GbE/1GbE interfaces. There
are 24 x SFP+ ports.
RJ-45 port with 10/100/1000 Mbps auto-negotiating
capability
Signal
Not supported
Not supported
RXD
GND
Not supported
TXD
Not supported
Not supported
Signal
Reserved
UART0_RX
UART0_TX
Minimum number Notes
of power supplies
1 x 650 W AC 1 power supply
1 x 650 W DC
1 x 650 W AC 2 power supplies
1 x 650 W DC
Maximum
ports
supported
12
24
1
Description
N/A
N/A
Receive data
Logic ground
N/A
Transmit data
N/A
N/A
Description
Not used
Debug port (data received by SLX)
Console port (data transmitted by
SLX)
