The following view shows the EKI-1224.
No. Item
1
DIN-Rail mounting
plate
2.3.3
Top View
No. Item
1
Terminal block
2
Ground terminal
3
Wall mounting holes Screw holes (top x4, bottom x4) used in the installation of a wall
EKI-1200-CE Series User Manual
1
Figure 2.7 Rear View
Description
Mounting plate used for the installation to a standard DIN rail
1
2
Figure 2.8 Top View
Description
Connect cabling for power and alarm wiring
Screw terminal used to ground chassis
mounting plate
12
3
