REDCAT ACCESS REGISTRATION GUIDE
REGISTRATION USING THE ACTIVATE APP
ADDING OR REPLACING A FLEXMIKE
For users adding a Flexmike, or replacing a lost or malfunctioning Flexmike.
1. Start with the Redcat plugged in and powered on.
2. If replacing a Flexmike, make sure the malfunctioning Flexmike is powered
off before you begin the process.
3. Power on the new Flexmike. Both microphone 1 and 2 blue lights should be
blinking.
4. Open the Flexmike battery compartment and pull the battery out (leaving it
plugged in) to reveal the registration button.
• If replacing a microphone, match the number 1 or 2 of the bad
microphone
• If adding a microphone, the new microphone would be number 2.
5. On your mobile device, open the Lightspeed Activate app.
6. Go to the 'Settings' tab and scroll down to find the 'Register' button and press the
button.
7. Tap the Mic 1 or Mic 2 button to add/replace the Flexmike.
8. Follow the instructions within the app to register the new Flexmike.
9. When the Flexmike is registered, you will see the Mic 1 or Mic 2 icon appear on the
screen.
10. The registration is complete. You can begin speaking into the Flexmike to verify there is audio.
11. Place system ID number (attached to the Redcat Quickstart Guide) on the new Flexmike.
NOTE: if at any point, the Redcat or Flexmike lights begin blinking rapidly, that indicates a registration error.
Turn off the Flexmike, then repeat steps 3-8.
REGISTER
AUDIO IN
MIN
MAX
AUDIO
(ALD) OUT
MIN
MAX
ON/OFF
DC INPUT
16V/2.0A
Blinking lights
Power On
(NEW Flexmike)
Registration ID Labels
Apply to system components to indicate which parts are registered
as a system. Keep registered items together when storing away.
334-0162-02-00-01 10101
00-01 00-01 00-01
00-01
00-01
00-01 00-01 00-01
00-01
00-01 00-01 00-01 00-01
00-01
00-01 00-01 00-01 00-01
00-01
00-01 00-01 00-01
00-01
00-01 00-01 00-01 00-01
00-01
RETAIN EXTRA LABELS IN THE EVENT A COMPONENT IS REPLACED OR ADDED.
