Figure 3-12, 14 Pin Target JTAG Cable
The target cable is flexible and about 13 inches long. It is made from micro coax cable.
This type of cable has the following flex/bend limitations.
1/8 inch minimum bend diameter
Figure 3-13, Target Cable Bend Limitations
Spectrum Digital, Inc
Cable
3-19
