- Page 1 XDS560v2 System Trace JTAG Emulator Technical Reference 2010 DSP Development Systems...
- Page 3 XDS560v2 System Trace JTAG Emulator Technical Reference 512105-0001 Rev. C August 2010 SPECTRUM DIGITAL, INC. 120502 Exchange Drive, #440 Stafford, TX. 77477 Tel: 281.494.4500 Fax: 281.494.5310 sales@spectrumdigital.com www.spectrumdigital.com...
- Page 4 IMPORTANT NOTICE Spectrum Digital, Inc. reserves the right to make changes to its products or to discontinue any product or service without notice, and advises its customers to obtain the latest version of relevant information to verify, before placing orders, that the information being relied on is current.
-
Page 5: Table Of Contents
....... . Lists the hardware and software you’ll need to install the XDS560v2 STM JTAG Emulator, and the installation procedure of the XDS560v2 STM in your system. - Page 6 JTAG Emulator. This emulator is designed to be used with digital signal processors (DSPs) and microcontrollers designed by Texas Instruments. The XDS560v2 System Trace JTAG Emulator is a table top module that attaches to a personal computer or laptop to allow hardware engineers and software programmers to develop applications with DSPs and microcontrollers.
-
Page 7: Introduction To The Xds560V2 Stm Jtag Emulator
Chapter 1 Introduction to the XDS560v2 STM JTAG Emulator This chapter provides you with a description of the XDS560v2 STM JTAG Emulator along with the key features. Topic Page Overview of the XDS560v2 STM JTAG Emulator Key Features of the XDS560v2 STM JTAG Emulator... - Page 8 Spectrum Digital, Inc 1.0 Overview of the XDS560v2 STM JTAG Emulator The XDS560v2 STM JTAG Emulator is designed to be used with digital signal processors (DSPs) and microprocessors which operate from +1.2 to +4.1 volt levels on the JTAG interface. The power for the emulator comes from the provided supply. This means no power is drawn from the target system or host PC.
-
Page 9: Key Items On The Xds560V2 Stm
Spectrum Digital, Inc 1.2 Key Items on the XDS560v2 STM JTAG Emulator Figure 1-1 shows the XDS560v2 STM. The key items identified are: • Status LEDs • JTAG Header • Emulator Tail Assembly • USB connector to the host PC or hub •... - Page 10 Spectrum Digital, Inc XDS560v2 STM JTAG Emulator Technical Reference...
-
Page 11: Installing The Xds560V2 Stm Jtag Emulator
Chapter 2 Installing the XDS560v2 STM JTAG Emulator This chapter helps you install the XDS560v2 STM JTAG Emulator. For use with specific software packages such as the TI’s Code Composer Studio refer to their respective documentation. Topic Page What You’ll Need... - Page 12 Spectrum Digital, Inc What You’ll Need The following checklists detail items that are shipped with the XDS560v2 STM JTAG emulator and additional items you’ll need to use these tools. Hardware checklist __ host computer An IBM PC/AT or 100% compatible PC or laptop running Windows...
- Page 13 Spectrum Digital, Inc 2.2 Installing the XDS560v2 STM JTAG Emulator The next three sections describe the steps for installing the XDS560v2 STM JTAG Emulator to interface to a PC or laptop via ethernet or USB. WARNING ! Target Cable Connectors: Be very careful with the target cable connectors.
- Page 14 Spectrum Digital, Inc The female JTAG connector attached to the end of the emulator tail plugs onto the target’s male pin header. The figure below shows how the XDS560v2 STM emulator header plugs onto the target’s JTAG header Emulator Tails...
- Page 15 Spectrum Digital, Inc These 4 adapters which come with the XDS560v2 STM are shown in the figure below. MIPI60 - CTI20 MIPI60 - ARM20 MIPI60 - TI14 MIPI60 - TI60 Figure 2-3, MIPI 60 to Target Connector Adapters 2.2.3 XDS560v2 STM Ethernet/USB Installation Checklist The following section provides instructions to install the XDS560v2 STM JTAG emulator using the Ethernet or USB interface.
- Page 16 Spectrum Digital, Inc ❏ Apply power to the XDS560v2 STM by connecting the power supply to the +5V input on the XDS560v2 STM located at the rear of the emulator. Figure 2-5, Applying Power to XDS560v2 STM When power is connected the “PWR” LED on the XDS560v2 STM should illuminate.
- Page 17 Align the emulator tail over the target connector, then push down Emulator tail attached to target Figure 2-7, Attaching the XDS560v2 STM Emulator Tail To Target ❏ Apply power to the target board.
- Page 18 Spectrum Digital, Inc Figures 2-8 and 2-9 show typical configurations in which the XDS560v2 STM can be used with a host PC and target board via the USB interface. Plugs into USB port on PC/Laptop ~ ! @ # $ % ^ & * ( ) _ + |...
- Page 19 Hub XDS560v2 STM JTAG Emulator Pod Emulator Plugs into Tail USB port on XDS560v2 +5 VDC Female JTAG Connector Male pin header 110/220 VAC Target DSP Power Supply or microcontroller Figure 2-9, Connecting the XDS560v2 STM Through a USB Hub...
- Page 20 Spectrum Digital, Inc Figures 2-10 and 2-11 show two typical configurations in which the XDS560v2 STM can be used with a host PC and target board via the Ethernet interface. Plugs into Ethernet port on PC/Laptop ~ ! @ # $ % ^ & * ( ) _ + |...
- Page 21 USB Cable JTAG Emulator Pod Emulator Plugs into Tail Ethernet port on XDS560v2 +5 VDC Female JTAG Connector Male pin header 110/220 VAC Target DSP Power Supply or microcontroller Figure 2-11, Connecting the XDS560v2 STM Through a Ethernet Hub 2-11...
- Page 22 Spectrum Digital, Inc 2.3 XDS560v2 STM LEDs The XDS560v2 STM has nine (9) Light Emitting Diodes (LEDs). These LEDs provide the user with the status of the emulator. The position of each LED is shown in the diagrams below. Activity LEDs...
- Page 23 The following sequences with approximate timings are provided for reference. From the sequences you can see that it may take the XDS560v2 around 60 seconds to boot so during this time do not power cycle the unit. Normal Boot Progress: POWER..ON time0...
-
Page 24: Reset Switch
Figure 2-14, XDS560v2 STM RESET Switch 2.5 Replacing the Emulator Tail Assembly The XDS560v2 STM JTAG emulator has a modular tail assembly. This allows the tail assembly and header to be replaced or upgraded if necessary. The next two sections describe the steps necessary to replace the XDS560v2 STM tail assembly. - Page 25 Figure 2-16, Removing the Header From Target Board ❏ Remove tail assembly from the XDS560v2 STM by unscrewing the 2 screws on each side of the connector. These screws should be able to be loosened by turning the screws counterclockwise. This can be done by hand but if necessary a flat blade screwdriver may be used.
-
Page 26: Installing The Emulator Tail Assembly
❏ Align the black connector on the tail assembly with the connector on the XDS560v2 STM. This is a keyed connector with the notched corners on the bottom side of the connector. Gently insert the black connector into the XDS560v2 STM. - Page 27 Emulator tail attached to target Figure 2-19, Attaching the XDS560v2 STM Emulator Tail To Target ❏ Plug the XDS560v2 STM power supply into the wall power outlet. ❏ Plug the power connector into the XDS560v2 STM. Figure 2-20, Applying Power To The XDS560v2 STM ❏...
- Page 28 Spectrum Digital, Inc 2-18 XDS560v2 STM JTAG Emulator Technical Reference...
-
Page 29: Specifications For Your Target System's Connection To The Emulator
Chapter 3 Specifications For Your Target System’s Connection to the Emulator This chapter contains information about connecting the XDS560v2 STM JTAG emulator to your target system. The emulator tail may plug directly onto the target board or use an intermediate adapter. - Page 30 Trace Connectors, Version 1.00.00, 5 June 2007 3.3 Physical Layout of MIPI 60 Connector The following two figures show the 60 pin MIPI header on the tail of the XDS560v2 STM JTAG emulator and the mating connector on an adapter or target board.
- Page 31 Spectrum Digital, Inc 3.4 MIPI 60 Connector Signals The following table shows the signals on the MIPI 60 pin connector. The greyed out signals are not supported. Table 1: MIPI 60 Connector Signals Signal Pin # Pin # Signal VREF_DEBUG...
-
Page 32: Emulator Tail Header Heights
JTAG connector. This height should be taken into consideration if the target board fits in an enclosure. The figure below shows the height of the tail header with adapters. Figure 3-2, XDS560v2 STM Emulator Tail Heights XDS560v2 STM JTAG Emulator Technical Reference... -
Page 33: Appendix A Mechanical Information
Appendix A Mechanical Information This appendix contains the mechanical information about the XDS560v2 STM JTAG Emulator produced by Spectrum Digital. - Page 34 Spectrum Digital, Inc The figure below provides the physical dimension of the XDS560v2 STM JTAG emulator. Figure A-1, XDS560v2 STM Dimensions Note: All dimensions are in inches and are nominal dimensions, unless otherwise specified. XDS560v2 STM JTAG Emulator Technical Reference...
- Page 36 Printed in U.S.A., August 2010 512105-0001 Rev C...
