3.3 XDS560R Emulator Cable Pod Logic
Figure 3-3 shows a portion of the XDS560R emulator cable pod. The following items
are characteristics of the XDS560R pod:
❏
Signals TMS, TDI and TRST are series terminated to reduce signal reflections.
❏
The TCK signal output has a medium-current drive capability of 24 mA I
The TCK signal is AC termination on the return side of the TCK (TCK_RET). The
termination voltage is set to 1/2 of the TVD voltage to minimize loading effects.
❏
The TDO signal from the slave device is terminated at the pod of the cable with a
10 KW resistor pulled up to the same voltage as set by TVD voltage.
❏
The trigger level for high-to-low and low-to-high transition for TDO, TCK_RET, and
EMU0/EMU1 is set to 1/2 of the TVD signal. For TVD voltages greater than 3.3 V, the
trigger level is set to approximately 1.65 V.
❏
Signals TMS and TDI, by default, are generated on the rising-edge of the TCK_RET
signal, but can be generated from the falling edge of TCK_RET to be in accordance
with the IEEE 1149.1 bus slave device timing rules.
❏
The pod provides a programmable (TCK) test clock source. The range of this TCK is
500 KHz to 50 MHz, but the operation is limited by timing of various signals and the
target devices. Note: All timing for the pod and emulator are from the TCK_RET
signal, therefore a user may provide their own test clock (TCK).
❏
All output signals from the pod are Hi-Z, whenever the pod power is turned on or
TVD signal is reduced by more than one third of its reset voltage.
❏
Signals TCK, TMS, TDI, and TRST have a 100 KW pull-down resistor. This is to
ensure that the target inputs are at a set level given that the outputs from the
XDS560R pod are Hi-Z after a power failure or disconnect.
❏
Pin 4 of the emulation header is the Target Disconnect (TDIS) signal. This signal is
used to detect if the target pod is connected to a target board. Pin 4 on the user
target board must be connected to ground.
❏
The impedance of the emulation pod cable is 50 ohms.
❏
Design Note: Pin 6 of the target emulation header is normally connected to a ground
signal on the target board. The target board designer may use this pin 6 as an
optional Host Disconnect (HDIS) signal. This signal could be used within the target
board to detect if the JTAG emulator cable/pod header is connected.
